| Specification | |
|---|---|
| Type | Vented |
| Outter Ø | 297 |
| Num. of holes | 6 |
| Disc Thickness (Max) | 25 |
| Height | 68 |
| Centering Diameter | 108 |
| Pitch Circle Ø | 139.7 |
| Front/Rear | Front |
| Owner | Number |
|---|---|
| ADVICS | A6F199B |
| Blue Print | ADT343211 |
| BREMBO | 09.A634.11 |
| BREMBO | 09A63410 |
| DBA | DBA2714 |
| DELPHI | BG4211 |
| Fri.tech. | DF1289 |
| JAPANPARTS | DI-2008 |
| LUCAS | DF4917 |
| LYNXauto | BN-1990 |
| NIPPARTS | N3302174 |
| NISSHINBO | ND1088K |
| NK | 2045140 |
| TOYOTA | 43512-0K060 |
| TOYOTA | 43512-0K070 |
| TOYOTA | 43512-0K071 |
| TOYOTA | 43512-0K080 |
| TOYOTA | 43512-0K250 |
| TRUSTING | DF1289 |
| TRW | DF4917 |
| TRW | DF7251 |
| Copyright © 2024 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 02.05~12.15 | 4000 | 1GR-FE | GGN50R | FR0430V | FP0976 | |||
| 01.05~07.11 | 2700 | 2TR-FE | GGN60 | FR0430V | FP0976 | |||
| 01.05~04.16 | 2500 | 2KD-FTV | KUN60L | FR0430VFR0799V | FP0976FP1567FP0799 | |||
| 01.05~10.15 | 2700 | 2TR-FE | TGN61R | FR0430V | FP0976FP1567FP0799 | |||
| 01.05~07.11 | 2700 | 2TR-FE | TGN65 | FR0430V | FP0976 | |||
| 01.05~04.12 | 2500 | 2KD-FTV | KUN50 | FR0430V | FP0799FP0976 | |||
| 06.06~07.11 | 2700 | 2TR-FE | KUN6 | FR0430V | FP0976 | |||
| 05.06~11.13 | 3000 | 5L-E | LAN50R | FR0430V | FP0976 | |||
| 01.05~08.07 | 2700 | 2TR-FE | TGN51R | FR0430V | FP0799 | |||
| 01.05~08.08 | 3000 | 1KD-FTV | KUN51R | FR0799VFR0430V | FP0976FP0799 | |||
| 01.16~ | 2400 | 2GD-FTV | GUN155R | FR1072VFR0430V | FR0658VFR0328V | FP0606FP1391 | FT1098 | |
| 01.05~04.16 | 2500 | 2KD-FTV | KUN60R | FR0430V | FP0799FP0976FP1567 | |||
| 03.16~ | 2400 | 2GD-FTV | GUN166R | FR0430V | FR0658V | FP1391FP0606 | FT1098 | |
| 07.15~04.21 | 2400 | 2GD-FTV | GUN165R | FR0430V | FR0658V | FP0606 | FT1098 |
| 07.11~ | 2500 | 2KD-FTV | KUN35R | FR0430V | FP1567 | |||
| 04.01~10.13 | 3000 | 5L-E | LAN25R | FR0430V | FP0799FP1567FP1726 | |||
| 08.04~12.08 | 2700 | 2TR-FE | TGN26L | FR0430V | FP0799 | |||
| 08.04~08.13 | 3000 | 1KD-FTV | KUN26R | FR0799VFR0430V | FP0976FP1567FP0799 | |||
| 02.05~12.15 | 2500 | 2KD-FTV | KUN25L | FR0430V | FP1567FP0799FP0976 | |||
| 03.05~01.16 | 2500 | 2KD-FTV | KUN25R | FR0430VFR0799V | FP1567FP0799FP0976 | |||
| 01.04~10.11 | 3000 | 1KD-FTV | KUN36L | FR0430V | FP0799FP0976 | FT1081 | ||
| 01.05~10.15 | 2500 | 2KD-FTV | KUN35L | FR0430V | FP0799 | FT1081 | ||
| 01.15~ | 2500 | 2KD-FTV | KUN122L | FR0430VFR0762V | FP2058 | FT1196 | ||
| 01.04~01.18 | 2700 | 2TR-FE | TGN36L | FR0430VFR0799V | FP1567FP0799FP0976 | FT1081 | ||
| 05.04~12.15 | 3000 | 1KD-FTV | KUN36R | FR0430VFR0799V | FP0799FP1567 | FT1081 | ||
| 08.11~10.13 | 3000 | 5L-E | LAN25R | FR0430V | FP1567 | FT1184 | ||
| 07.05~12.15 | 3000 | 5L-E | LAN25L | FR0430V | FP0799FP1567FP1726 | |||
| 05.15~07.17 | 2500 | 2KD-FTV | KUN125R | FR0430VFR0799V | FP1567FP0976 | |||
| 05.15~ | 2400 | 2GD-FTV | GUN125R | FR0799VFR0430V | FP0976FP1567 | |||
| 01.04~01.18 | 2700 | 2TR-FE | TGN36R | FR0799VFR0430V | FP0976FP1567 | FT1184 | ||
| 11.15~ | 2700 | 2TR-FE | TGN126L | FR0799VFR0430VFR0551V | FP1567FP0976 | FT1081 | ||
| 01.21~ | 2700 | 2TR-FE | TGN127L | FR0430VFR0799VFR0551V | FP1567FP0976 | FT1081 | ||
| 07.16~ | 2700 | 2TR-FE | TGN128L | FR0430VFR0799VFR0551V | FP1567FP0976 | FT1081 | ||
| 04.05~01.19 | 2700 | 2TR-FE | TGN36L | FR0430V | FP0799FP1567 | FT1081 | ||
| 05.05~10.13 | 3000 | 5L-E | LAN35R | FR0430V | FP1567FP0799 | FT1184 | ||
| 01.15~05.19 | 2500 | 2KD-FTV | KUN122R | FR0430VFR0762V | FP2058 | FT1196 | ||
| 07.05~12.15 | 3000 | 5L-E | LAN125L | FR0430V | FP1567 | FT0022 |
