| Specification | |
|---|---|
| Type | Vented |
| Disc Thickness (Max) | 28 |
| Num. of holes | 6 |
| Height | 48.2 |
| Centering Diameter | 105 |
| Front/Rear | Front |
| Pitch Circle Ø | 127 |
| Outter Ø | 285 |
| Drum Ø: | 155 |
| Disc Thickness (Min) | 26 |
| Structure Material | G3000 |
| Owner | Number |
|---|---|
| Blue Print | ADT343314 |
| BOSCH | 0 986 T15 178 |
| BREMBO | 09B06310 |
| DBA | DBA2732 |
| DELPHI | BG4210 |
| Fri.tech. | DF1463 |
| HI-Q | SD4005 |
| JAPANPARTS | DI-2046 |
| LYNXauto | BN-1994 |
| NISSHINBO | ND1049 |
| TOYOTA | 43512-26190 |
| TOYOTA | 43512-56190 |
| TRADEX | TBD1107 |
| TRUSTING | DF1463 |
| TRW | DF7317 |
| Copyright © 2024 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.03~12.13 | 2500 | 2KD-FTV | KDH205V | FR0441V | FP1067 | FT0871 | ||
| 08.04~ | 2000 | 1TR-FE | TRH200V | FR0441V | FP1067 | FT0871 | ||
| 08.09~ | 3000 | 1KD-FTV | KDH211K | FR0441V | FP1067 | FT0871 | ||
| 08.04~ | 2700 | 2TR-FE | TRH214W | FR0441V | FP1067 | FT0871 | ||
| 01.05~09.07 | 2500 | 2KD-FTV | KDH222B | FR0441V | FP1067 | FT0871 | ||
| 01.05~ | 2700 | 2TR-FE | TRH226 | FR0441V | FP1067 | FT0871 | ||
| 12.17~ | 2800 | 1GD-FTV | GDH201V- | FR0441V | FP1067 | FT0871 | ||
| 12.17~ | 2800 | 1GD-FTV | GDH211K | FR0441V | FP1067 | FT0871 | ||
| 12.17~ | 2800 | 1GD-FTV | GDH223B | FR0441V | FP1067 | FT0871 | ||
| 08.04~12.13 | 2700 | 2TR-FE | TRH219W | FR0441V | FP1067 | FT0871 | ||
| 01.05~08.07 | 2500 | 2KD-FTV | KDH225K | FR0441V | FP1067 | FT0871 | ||
| 01.05~ | 2700 | 2TR-FE | TRH224W | FR0441V | FP1067 | FT0871 | ||
| 09.07~10.17 | 3000 | 1KD-FTV | KDH201V | FR0441V | FP1067 | FT0871 | ||
| 07.10~ | 3000 | 1KD-FTV | KDH206V | FR0441V | FP1067 | FT0871 | ||
| 08.04~08.07 | 2500 | 2KD-FTV | KDH200V | FR0441V | FP1067 | FT0871 | ||
| 08.04~08.07 | 2500 | 2KD-FTV | KDH200K | FR0441V | FP1067 | FT0871 | ||
| 09.07~ | 3000 | 1KD-FTV | KDH201K | FR0441V | FP1067 | FT0871 | ||
| 09.07~ | 3000 | 1KD-FTV | KDH206K | FR0441V | FP1067 | FT0871 | ||
| 01.05~09.07 | 2500 | 2KD-FTV | KDH220K | FR0441V | FP1067 | FT0871 | ||
| 09.07~11.17 | 3000 | 1KD-FTV | KDH221K | FR0441V | FP1067 | FT0871 | ||
| 08.04~12.13 | 2000 | 1TR-FE | TRH200K | FR0441V | FP1067 | FT0871 | ||
| 09.07~ | 2700 | 2TR-FE | TRH211K | FR0441V | FP1067 | FT0871 | ||
| 09.07~ | 2700 | 2TR-FE | TRH216K | FR0441V | FP1067 | FT0871 | ||
| 01.05~ | 2700 | 2TR-FE | TRH221K | FR0441V | FP1067 | FT0871 | ||
| 01.05~ | 2700 | 2TR-FE | TRH228B | FR0441V | FP1067 | FT0871 | ||
| 01.05~08.10 | 2500 | 2KD-FTV | KDH227B | FR0441V | FP1067 | FT0871 | ||
| 01.18~ | 2800 | 1GD-FTV | GDH206V- | FR0441V | FP1067 | FT0871 |
| 01.05~02.14 | 2700 | 2TR-FE | TRH221R | FR0441V | FP1067 | FT0871 | ||
| 01.05~ | 3000 | 1KD-FTV | KDH201R | FR0441V | FP1067 | FT0871 | ||
| 01.05~02.14 | 3000 | 1KD-FTV | KDH203R | FR0441V | FP1067 | FT0871 | ||
| 01.05~02.14 | 2500 | 2KD-FTV | KDH200R | FR0441V | FP1067 | FT0871 | ||
| 08.05~ | 2700 | 2TR-FE | TRH223L | FR0441V | FP1067 | FT0871FT1184 | ||
| 01.05~02.14 | 3000 | 1KD-FTV | KDH223R | FR0441V | FP1067 | FT0871FT1184 | ||
| 01.05~09.07 | 2500 | 2KD-FTV | KDH202R | FR0441V | FP1067 | FT0871 | ||
| 08.04~08.10 | 2700 | 2TR-FE | TRH221W | FR0441V | FP1067 | FT0871 | ||
| 01.13~ | 3000 | 5L-E | LH212 | FR0441V | FP1067 | FT0871 | ||
| 01.13~ | 2500 | 2KD-FTV | KDH212R | FR0441V | FP1067 | FT0871 | ||
| 01.05~01.05 | 3000 | 5L-E | LH202 | FR0441V | FP1067 | FT0871 | ||
| 01.05~02.14 | 2700 | 2TR-FE | TRH221L | FR0441V | FP1067 | FT0871 | ||
| 02.06~01.14 | 2500 | 2KD-FTV | KDS200 | FR0441V | FP1067 | FT0871 | ||
| 09.07~01.14 | 2500 | 2KD-FTV | KDS202 | FR0441V | FP1067 | FT0871 | ||
| 01.05~09.13 | 2500 | 2KD-FTV | KDH202L | FR0441V | FP1067 | FT0871 | ||
| 08.04~05.12 | 2500 | 2KD-FTV | KDH222R | FR0441V | FP1067 | FT0871FT1184 | ||
| 01.05~ | 2700 | 2TR-FE | TRH223B | FR0441V | FP1067 | FT0871 | ||
| 08.04~ | 2700 | 2TR-FE | TRH229W | FR0441V | FP1067 | FT0871 | ||
| 01.05~ | 2700 | 2TR-FE | TRH203R | FR0441V | FP1067 | FT0871 | ||
| 01.05~ | 2500 | 2KD-FTV | KDH222L | FR0441V | FP1067 | FT0871FT1184 | ||
| 01.05~01.21 | 2700 | 2TR-FE | TRH201R | FR0441V | FP1067 | FT0871 | ||
| 01.05~02.19 | 3000 | 5L-E | LH222R | FR0441V | FP1067 | FT1184FT0022FT0871 | ||
| 01.05~ | 2700 | 2TR-FE | TRH203L | FR0441V | FP1067 | FT0871 | ||
| 01.05~ | 2700 | 2TR-FE | TRH221L | FR0441V | FP1067 | FT0871 | ||
| 01.05~01.21 | 2700 | 2TR-FE | TRH201L | FR0441V | FP1067 | FT0871 | ||
| 01.17~ | 2800 | 1GD-FTV | GDH201R | FR0441V | FP1067 | FT0871 |
| 01.06~ | 2700 | 2TR-FE | TRH223R | FR0441V | FP1067 | FT0871 | ||
| 09.07~ | 3000 | 1KD-FTV | KDH223B | FR0441V | FP1067 | FT0871 | ||
| 01.06~12.13 | 2700 | 2TR-FE | TRH213R | FR0441V | FP1067 | FT0871 | ||
| 01.05~ | 2500 | 2KD-FTV | KDH222R | FR0441V | FP1067 | FT1184FT0871FT0022 | ||
| 01.05~12.16 | 2700 | 2TR-FE | TRH213L | FR0441V | FP1067 | FT0871 |
