FiT » ROTOR DISC » FR0934V Feedback Information NEW!

Image Of FR0934V
Specification
Type Vented
Disc Thickness (Max) 24
Num. of holes 6
Height 24.2
Centering Diameter 86
Front/Rear Front
Pitch Circle Ø 108
Outter Ø 256
Owner Number
Blue Print ADM54385
Blue Print ADM54390
BREMBO 09.A862.10
DELPHI BG3559
FORD 1454363
FORD 3902826
FORD 4883102
MAZDA S617-33-25X
MAZDA SE20-33-251
MAZDA SE20-33-25X
MAZDA UH71-33-251
MAZDA UH81-33-251
MAZDA UR66-33-251
NISSHINBO ND5022
SANGSIN SD4406
TEXTAR 92136200
TRW DF 4898
Copyright © 2024
Years Eng Vol Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
MAZDA   »   BT-50
09.06~07.08 2600 G6-E ALUA07 FR0570VFR1087VFR0934V FP5158FP1574FP1374 FT5234FT5247FT5248
08.06~09.11 3000 WEAT ALUA07 FR0570VFR1087VFR0934V FP5158FP1574FP1374 FT5234FT5248FT5247
09.06~09.11 2200 F2 UN FR0570VFR1087VFR0934V FP5158FP1574FP1374 FT5234FT5248FT5247
07.08~09.12 2500 WLAA UN FR0570VFR1087VFR0934V FP5158FP1574FP1374 FT5234FT5248FT5247
MAZDA   »   E2500
11.96~12.98 2500 WL SDY FR0934VFR0745V FP5152 FT5223FT5224FT5225
MAZDA   »   E2200
11.96~12.04 2200 R2 SR1 FR0934V FP5152 FT5224
MAZDA   »   Bongo Brawny
04.97~06.99 2500 WL SR59V FR0934V FP5152 FT5224FT5225
09.93~06.99 1800 F8 SD89T FR0934V FT5227FP5152 FT5224FT5225
MAZDA   »   B2500
08.02~01.07 2500 WL AUEA05 FR0570VFR1087VFR0934V FP1574FP1374 FT5248FT5247
02.99~08.02 2500 WL AUEA4 FR0934V FP1374 FT5247FT5248
11.98~08.02 2500 WL ABUA4 ER FR0934V FP1374 FT5247FT5248
MAZDA   »   B2600
11.98~01.07 2600 G6 UN FR0934V FP1374 FT5247
MAZDA   »   B2200
08.02~12.06 2200 F2 ALUA06 FR0934V FP1374 FT5247
FORD   »   Ranger
06.98~07.03 2500 WL-T ER FR0934V FP1374 FT5248FT5247
06.02~10.07 2500 2.5 Diesel TI (HP) EQ FR0570VFR1087VFR0934V FP1374 FT5248FT5247
06.02~10.07 2900 2.9L SOHC NA I4 MN#80 FR0570VFR1087VFR0934V FP1374FP1574 FT5248
02.06~12.09 2200 2.2L EFI ET FR0570VFR1087VFR0934V FP1574FP1374 FT2095FT5247
06.02~10.07 2500 2.5 Diesel TI (NP) EQ FR0934V FP1374 FT5248
05.06~12.11 2500 2.5 Diesel TI (HP) MN#40 FR0570VFR1087VFR0934V FP1574FP1374 FT2095FT5247
11.02~10.07 2200 2.2 EFI EQ FR0934V FP1374 FT5248
