FiT » ROTOR DISC » FR1155V Feedback Information NEW!

Image Of FR1155V
Specification
Type Vented
Outter Ø 307
Num. of holes 5
Disc Thickness (Max) 16
Height 67
Centering Diameter 62
Pitch Circle Ø 114.3
Drum Ø: 177
Front/Rear Rear
Owner Number
Blue Print ADT343296
DELPHI BG3588
HELLA 8DD 355 114-941
Jakoparts J3312063
TOYOTA 42431-14150
TOYOTA 42431-14170
TOYOTA 42431-22170
Copyright © 2024
Years Eng Vol Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
TOYOTA   »   Chaser
09.96~07.01 2500 1JZ-GTE JZX100 (TOURER V) FR0262V FP0476FP0619 FR1155V FP1064FP0771
10.92~09.96 2500 1JZ-G## JZX90 FR0416VFR0262V FP0476FP0619 FR0592FR1155V FP0672FP0572
TOYOTA   »   Mark II
09.96~07.01 2500 1JZ-GE JZX100 FR0262VFR0416V FP0476FP0619 FR0592FR1155V FP1064FP0572FP0771
10.92~09.96 2500 1JZ-GE JZX90 FR0416VFR0262V FP0619FP0476 FR0592FR1155V FP0672
TOYOTA   »   Cresta
09.96~07.01 2500 1JZ-GTE JZX100 FR0262V FP0476FP0619 FR1155V FP1064FP0771
10.92~09.96 2500 1JZ-GTE JZX90 FR0262V FP0619 FR1155V FP0672
TOYOTA   »   Supra
05.93~08.02 3000 2JZ-GE JZA80L FR0262V FP0619FP0629 FR0593VFR1155V FP0572FP0630 FT0846
