| Specification | |
|---|---|
| Type | Vented |
| Outter Ø | 290 |
| Num. of holes | 6 |
| Disc Thickness (Max) | 26 |
| Height | 46.4 |
| Centering Diameter | 94 |
| Front/Rear | Front |
| Pitch Circle Ø | 139.7 |
| Drum Ø: | 171 |
| Owner | Number |
|---|---|
| AC Delco | AC2499D |
| APEC | DSK2198 |
| ATE | 24.0126-0124.1 |
| ATE | 24.0126-0145.1 |
| Blue Print | ADC443110 |
| BOSCH | 0 986 478 990 |
| BREMBO | 09.9996.10 |
| BREMBO | 09.A911.10 |
| CAR | 142.028 |
| CAR RACING | HPD 028 |
| CIFAM | 800-777 |
| DELPHI | BG3812 |
| DENCKERMANN | B130578 |
| Febi | 26048 |
| FERODO | DDF1384 |
| Fri.tech. | DF730 |
| GIRLING | 6043691 |
| GRAF | DF29777 |
| HI-Q | SD4306 |
| INTERBRAKE | MB631V |
| KWP | 129777 |
| LPR | M1016V |
| LPR | M1604V |
| LUCAS | DF4159 |
| LUCAS | DF4369 |
| LUCAS | DF4942 |
| LYNXauto | BN-1090 |
| Mando | MBC030119 |
| Metelli | 23-0777 |
| MINTEX | MDC1576 |
| MINTEX | MDC2040 |
| MITSUBISHI | 4615A061 |
| MITSUBISHI | MR407116 |
| MITSUBISHI | MR407289 |
| NECTO | WN1348 |
| NIPPARTS | J3305052 |
| NISSHINBO | 4615A061 |
| NISSHINBO | ND3027K |
| NK | 203054 |
| OEM | MN116706 |
| OEM | ZB403101 |
| PAGID | 54288 |
| PILENGA | V622 |
| QH | BDC5266 |
| REMSA | 6639.10 |
| REMSA | 6873.20 |
| ROADHOUSE | 6639.10 |
| ROADHOUSE | 6873.20 |
| SBS | 1815203033 |
| SWAG | 80926048 |
| TEXTAR | 92128800 |
| TRADEX | TBD1141 |
| TRUSTING | DF730 |
| TRW | DF4369 |
| TRW | DF4870 |
| VALEO | 186813 |
| WOKING | D6639.10 |
| ZIMMERMANN | 380.2169.00 |
| Copyright © 2025 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 02.00~01.07 | 2500 | 4D56-T | V74W | FR0301V | FP0867 | FR0360V | FP0868 | |
| 10.06~10.12 | 3800 | 6G75 | V87W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 02.00~12.06 | 2800 | 4M40-T | V76W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 02.00~12.06 | 3800 | 6G75 | V77W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 08.06~02.15 | 3000 | 6G72 | V93W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 09.06~ | 2800 | 4M40 | V96W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 02.00~12.06 | 3000 | 6G72 | V73W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 01.99~11.05 | 3500 | 6G74 | V75W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 01.99~07.06 | 3200 | 4M41-T | V68W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 01.99~11.05 | 3500 | 6G74 | V65W | FR0301V | FP0867 | FR0360V | FP0868 | |
| 09.06~08.14 | 3200 | 4M41-T | V88W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 02.00~12.06 | 3200 | 4M41-T | V78W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 08.06~ | 3500 | 6G74 | V95W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 09.14~ | 3000 | 6G72 | V93W RUS | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 05.03~01.07 | 3000 | 6G72 | V63W GL | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 05.99~05.03 | 3200 | 4M41-T | V78W ER | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 02.00~01.07 | 2500 | 4D56-T | V64W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 09.99~11.06 | 3500 | 6G74 | V75W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 02.00~12.06 | 3800 | 6G75 | V77W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 09.99~11.05 | 3200 | 4M41-T | V68W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 10.06~ | 3000 | 6G72 | V93W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 10.06~11.12 | 3800 | 6G75 | V87W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 03.09~03.18 | 3200 | 4M41 | V88W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 08.00~09.06 | 3000 | 6G72 | V73W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 08.00~09.06 | 3000 | 6G72 | V63W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 02.00~01.07 | 2500 | 4D56-T | V64W | FR0301VFR0408V | FP0867 | FR0360V | FP0868 | |
| 09.99~11.05 | 3200 | 4M41-T | V68W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 01.99~11.05 | 3500 | 6G74 | V75W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
| 02.00~12.06 | 3200 | 4M41-T | V78W | FR0301V | FP0867 | FR0360V | FP0868 | FT0087 |
