FiT » ROTOR DISC » FR0504V Feedback Information NEW!

Image Of FR0504V
Specification
Type Vented
Disc Thickness (Max) 32
Num. of holes 5
Height 54.7
Centering Diameter 67
Front/Rear Front
Pitch Circle Ø 112
Outter Ø 330
Disc Thickness (Min) 30
Drum Ø: 156
Structure Material G3000
Owner Number
ATE 24.0132-0158.1
BREMBO 09.R104.11
CAR 142.1205
CAR RACING HPD 1205
CIFAM 800-937
CIFAM 800-937C
DELPHI BG9968
FERODO DDF1533
FERODO DDF1533C
Fri.tech. DF1043
GIRLING 6044711
GIRLING 6044715
INTERBRAKE MD171V
JURID 562343J
JURID 562403J
LPR M2029V
LUCAS DF4471
LUCAS DF4471S
LYNXauto BN-1717
MERCEDES-BENZ 1644210412
MERCEDES-BENZ 1644211312
MERCEDES-BENZ A 164 421 13 12
MERCEDES-BENZ A1644210412
Metelli 23-0937
Metelli 23-0937C
MINTEX MDC2068
PAGID 54506
PILENGA V926
SBS 1815203392
SBS 1815343392
TEXTAR 92150600
TEXTAR 92150605
TRUSTING DF1043
TRW DF4471
TRW DF4471S
ZIMMERMANN 400.3648.00
Copyright © 2024
Years Eng Vol Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
MERCEDES-BENZ   »   ML 300
03.10~12.11 3000 M 272.945 W164 FR0504V FR0645 FP1122 FT0096
MERCEDES-BENZ   »   ML 320
10.05~12.11 3000 OM 642.940 W164 FR0504V FR0644VFR0645 FP1122 FT0096
MERCEDES-BENZ   »   R 320
01.06~07.10 3000 OM 642.950 W251 FR0504V FR0645FR0644V FP1122 FT0096
MERCEDES-BENZ   »   R 350
09.05~12.17 3500 M 272.967 S251 FR0504V FR0645 FP1122 FT0096
08.10~12.14 3000 OM 642.872 W251 FR0504VFR0836VFR0839V FR0645FR0644V FP1122 FT0096
05.09~12.14 3000 OM 642.870 W251 FR0504VFR0836VFR0839V FR0644V FP1122 FT0096
08.05~12.12 3500 M 272.967 W251 FR0504V FR0645FR0644V FP1122 FT0096
MERCEDES-BENZ   »   ML 280
09.05~09.11 3000 OM 642.940 W164 FR0504V FR0645 FP1122 FT0096
MERCEDES-BENZ   »   ML 350
02.05~12.11 3500 M 272.967 164.186 FR0504V FR0645 FP1122 FT0096
MERCEDES-BENZ   »   R 280
01.07~01.10 3000 M 272.945 W251 FR0504V FR0645FR0644V FP1122 FT0096
06.06~06.09 3000 OM 642.950 W251 FR0504VFR0836VFR0839V FR0645FR0644V FP1122 FT0096
MERCEDES-BENZ   »   R 300
07.09~12.12 3000 OM 642.950 W251 FR0504VFR0836VFR0839V FR0645FR0644V FP1122 FT0096
