| Specification | |
|---|---|
| Type | Solid |
| Disc Thickness (Max) | 12 |
| Num. of holes | 5 |
| Height | 55 |
| Centering Diameter | 62 |
| Front/Rear | Rear |
| Pitch Circle Ø | 114.3 |
| Outter Ø | 281 |
| Drum Ø: | 173 |
| Disc Thickness (Min) | 10.6 |
| Owner | Number |
|---|---|
| Ashika | 6102230 |
| ATE | 24.0112-0714.1 |
| Blue Print | ADT343207 |
| BREMBO | 08.A429.10 |
| CAR | 142.1303 |
| DENCKERMANN | B130618 |
| Febi | 29353 |
| FENOX | TB215343 |
| FERODO | DDF1846 |
| Fri.tech. | DF1152 |
| HI-Q | SD4094 |
| INTERBRAKE | TT301P |
| LPR | T2030P |
| LUCAS | DF4829 |
| LYNXauto | BN-1137 |
| MILES | K010700 |
| MILES | K210700 |
| MINTEX | MDC1826 |
| NISSHINBO | ND1013K |
| NK | 2045114 |
| SASIC | 6106268 |
| SBS | 18152045114 |
| STELLOX | 6020-1130-SX |
| SWAG | 81929353 |
| TEXTAR | 92162103 |
| TOYOTA | 42431-0R010 |
| TOYOTA | 42431-42060 |
| TRADEX | TBD1121 |
| TRUSTING | DF1152 |
| TRW | DF4829 |
| ZEKKERT | BS-5422 |
| ZIMMERMANN | 590280120 |
| Copyright © 2025 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 02.09~ | 2200 | 2AD-FHV | ZSA30 | FR0540V | FP1211 | FR0539 | FP1212 | FT0082 |
| 11.05~12.12 | 2400 | 2AZ-FE | ACA33R | FR0352V | FP1211FP1210 | FR0539 | FP1212 | FT0082 |
| 12.12~10.15 | 2000 | 3ZR-FAE | ZSA44R | FR0352VFR0331V | FP1211 | FR0539 | FP1212 | FT0082 |
| 11.05~12.12 | 2000 | 1AZ-FE | ACA30L | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 11.05~12.12 | 2400 | 2AZ-FE | ACA36W | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 01.05~01.13 | 2500 | 2AR-FE | ASA38L | FR0540V | FP1210 | FR0539 | FP1212 | FT0082 |
| 12.12~ | 2000 | 3ZR-FE | ZSA44L | FR0331VFR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 11.05~07.16 | 2400 | 2AZ-FE | ACA31W JPN | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 12.12~10.15 | 2500 | 2AR-FE | ASA42L | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 12.12~09.19 | 2000 | 3ZR-FE | ZSA42L | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 11.05~ | 2000 | 1AZ-FE | ACA30R | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 11.05~12.12 | 2400 | 2AZ-FE | ACA38 | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 01.05~01.13 | 3500 | 2GR-FE | GSA38L | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 12.12~09.19 | 2200 | 2AD-FHV | ALA49L | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 12.12~ | 2000 | 3ZR-FAE | ZSA44L | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 12.08~12.12 | 2000 | 3ZR-FAE | ZSA35L | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 12.08~12.12 | 2000 | 3ZR-FAE | ZSA30L | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 12.08~12.12 | 2400 | 2AZ-FE | ACA33L | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 01.07~12.08 | 2400 | 2AZ-FE | ACA31L | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 01.08~01.13 | 2500 | 2AR-FE | ASA33L | FR0540V | FP1210 | FR0539 | FP1212 | FT0082 |
| 11.05~11.13 | 2400 | 2AZ-FE | ACA33W | FR0352V | FP1210FP1211 | FR0539 | FP1212 | FT0082 |
| 12.12~12.18 | 2500 | 2AR-FE | ASA44L | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 12.12~09.19 | 2200 | 2AD-FTV | ALA49L | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 11.05~01.13 | 3500 | 2GR-FE | GSA33L | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 08.07~08.08 | 3500 | 2GR-FE | GSA33R | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 11.05~12.12 | 2200 | 2AD-FHV | ALA30L | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 01.13~12.15 | 2500 | 2AR-FE | ASA44R | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 12.12~12.18 | 2000 | 3ZR-FE | ZSA42R | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 11.05~12.12 | 2200 | 2AD-FHV | ALA30R | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 10.15~10.18 | 2000 | 2A-RFXE | AVA44L | FR0352VFR0549V | FP1211FP1324 | FR0539 | FP1212 | FT0082 |
| 10.15~10.18 | 2000 | 2A-RFXE | AVA42L | FR0352VFR0549V | FP1211FP1324 | FR0539 | FP1212 | FT0082 |
| 08.09~12.12 | 2200 | 2AD-FTV | ALA35 | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 12.12~10.15 | 2000 | 1AD-FTV | ALA40L | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 03.10~01.13 | 2400 | 2AZ-FE | ACA38L GCC | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 10.15~12.18 | 2500 | 2AR-FE | ASA44L US NAP | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 09.07~10.13 | 2400 | 2AZ-FE | ANA10 | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 09.07~10.13 | 2400 | 2AZ-FE | ANA15 | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 09.07~10.13 | 3500 | 2GR-FE | GGA10 | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 01.14~05.20 | 2000 | 3ZR-FAE | ZSU60W | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 01.14~05.20 | 2500 | 2AR-FXE | AVU65W | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 12.13~05.17 | 2000 | 3ZR-FAE | ZSU65W | FR0352VFR0549V | FP1211FP1324 | FR0539FR0757 | FP1212FP1805 | FT0082 |
| 08.07~01.13 | 2400 | 2AZ-FE | ACA33W | FR0352V | FP1211 | FR0539 | FP1212 | |
| 08.07~12.12 | 3500 | 2GR-FE | GSA33W | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 08.08~11.13 | 2400 | 2AZ-FE | ACA38W | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 11.05~11.12 | 2400 | 2AZ-FE | ACA31W | FR0352V | FP1211 | FR0539 | FP1212 | FT0082 |
| 07.09~01.12 | 2400 | 2AZ-FXE | ANF10L | FR0540V | FP1210 | FR0539 | FP1212 | FT0082 |
| 07.09~02.18 | 2400 | 2AZ-FXE | ANF10 | FR0540V | FP1210 | FR0539 | FP1212 | FT0082 |
