FiT » ROTOR DISC » FR0580V Feedback Information NEW!

Image Of FR0580V
Specification
Type Vented
Disc Thickness (Max) 25
Num. of holes 5
Height 46.5
Centering Diameter 84
Front/Rear Front
Pitch Circle Ø 110
Outter Ø 255
Owner Number
AC Delco AC2548D
AP 24556
Blue Print ADT34360
BOSCH 0 986 478 452
BRADI 1.5298.2.4
BRECO BS 8180
BREMBO 09.6710.10
CAR 142.641
CAR RACING HPD 641
DELPHI BG3174
FERODO DDF703
Fri.tech. DF426
GIRLING 6027451
INTERBRAKE TY761V
INTERCAR TY761V
JURID 561746J
LPR T2761V
LUCAS DF2745
MINTEX MDC1072
NECTO WN803
NISSHINBO ND1096
PAGID 53641
PILENGA 8025
PILENGA V672
QH BDC4818
SBS 171726
SBS 1815204537
TEXTAR 92080300
TOYOTA 43512-04030
TOYOTA 43512-20090
TOYOTA 43512-26090
TRUSTING DF426
TRW DF2745
VALEO 186674
Copyright © 2024
Years Eng Vol Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
TOYOTA   »   Hiace Regius
08.89~08.96 2800 3L LH113V FR0580VFR0377V FP1045FP1344FP1067 FT1194FT1189
08.98~08.04 3000 5L-E LH162R FR0583VFR0580V FP1045FP1344FP1067 FT1196FT1194
08.86~08.96 2800 3L LH123V FR0580VFR0377V FP1045FP1344FP1067 FT1189FT1194
08.89~08.96 2000 1RZ-E RZH112V FR0377VFR0580V FP1344FP1045FP1067 FT1194FT1189FT1196
08.89~07.96 2800 3L LH125B FR0580VFR0583V FP1045 FT1189FT1194
08.89~08.93 2400 2RZ-E RZH101G FR0580VFR0583V FP1045FP1344FP1067 FT1189FT1194
10.90~05.95 2400 2L LH140G FR0136VFR0580V FP1045 FT1189
08.89~08.93 2400 2L LH110G FR0580V FP1045 FT1189
08.89~07.93 2000 1RZ-E RZH100G FR0583VFR0580V FP1045FP1344FP1067 FT1189FT1194
01.89~01.04 2400 2L-TE LH100G FR0580V FP1045 FT1189
08.89~07.99 2000 1RZ-E RZH110G FR0580V FP1045 FT1189
08.89~08.96 2000 1RZ-# RZH112K FR0377VFR0580V FP1344FP1045FP1067 FT1194FT0764FT1196
08.89~08.96 2000 1RZ-# RZH124B FR0580VFR0583VFR0377V FP1045FP1344FP1067 FT1194FT1189
10.90~08.93 2400 2L-TE LH120G FR0580V FP1045 FT1189
08.89~08.96 2000 1RZ-E RZH102V FR0580VFR0377V FP1045FP1344FP1067 FT1189FT1194
08.89~08.93 2000 1RZ-E RZH122V FR0580V FP1045 FT1189
TOYOTA   »   Hiace Commuter
08.89~07.99 2800 3L LH103L FR0580V FP1045 FT1194
08.89~02.06 3000 5L-E LH174R FR0580VFR0583V FP1045FP1344FP1067 FT1194
08.89~01.00 2800 3L LH115R FR0580VFR0583V FP1045FP1344 FT1194FT1189
08.89~01.00 2800 3L LH115B FR0580VFR0583V FP1045 FT1189FT1194
08.89~08.04 2400 2L LH102L FR0580VFR0583V FT1163FP1045FP1344FP1067
08.89~08.93 2000 1RZ-E RZH102L FR0580V FT1163FP1045 FT1189FT1194
08.89~02.06 2400 2RZ RZH103R FR0580VFR0583V FP1045FP1344 FT1189FT1194
TOYOTA   »   Hiace
08.93~08.99 2800 3L LH103V FR0583VFR0580V FP1045FP1344 FT1194
08.89~08.93 2400 2L LH102V FR0580V FP1045 FT1189
08.89~08.96 2800 3L LH113K FR0580VFR0377V FP1045 FT1189FT1194
08.89~08.93 2400 2L LH100G FR0580V FP1045 FT1189
08.89~01.05 2400 2RZ-E RZH113L FR0580VFR0583V FP1045FP1344FP1067 FT1194FT1189
TOYOTA   »   Hiace Van
08.89~08.05 2400 2RZ-E RZH115L FR0583VFR0580V FP1045FP1344FP1067 FT1194
08.89~02.06 2400 2L LH112R FR0580VFR0583V FP1045FP1344FT1163FP1067 FT1194
08.89~02.06 2000 1RZ-E RZH102 FR0580VFR0583V FP1344FP1045 FT1189FT1194
08.89~09.05 2800 3L LH113R FR0580VFR0583V FP1045FP1344FT1163FP1067 FT1194
08.89~02.06 2400 2L LH114R FR0580VFR0583V FP1045FP1344FT1163FP1067
TOYOTA   »   Hilux
08.01~08.05 2500 2KD-FTV KDN145 FR0580V FP0799FP0438 FT0764
08.85~08.05 2400 2L LN145R FR0136VFR0580V FP0438FP0799 FT1194FT0764
