| Specification | |
|---|---|
| Type | Vented |
| Outter Ø | 256 |
| Num. of holes | 4 |
| Disc Thickness (Max) | 22 |
| Height | 44.3 |
| Centering Diameter | 62 |
| Pitch Circle Ø | 100 |
| Front/Rear | Front |
| Drum Ø: | 125 |
| Owner | Number |
|---|---|
| Blue Print | ADG043177 |
| BREMBO | 09.C171.10 |
| BREMBO | 09.C171.11 |
| Febi | 108447 |
| FREMAX | BD-5206 |
| HYUNDAI | 51712-0U000 |
| HYUNDAI | 51712-1R000 |
| HYUNDAI | 51712-1S300 |
| HYUNDAI | 51712-1W200 |
| HYUNDAI | 51712-1W250 |
| HYUNDAI | 51712-R1300 |
| HYUNDAI / KIA | 51712-0U100 |
| HYUNDAI / KIA | 51712-0U500 |
| HYUNDAI / KIA | 51712-K8100 |
| Jakoparts | J3300340 |
| KIA | 51712-0U000 |
| KIA | 51712-1W250 |
| LYNXauto | BN-1431 |
| MINTEX | MDC2344 |
| NISSHINBO | ND6031K |
| SANGSIN | SD2039 |
| SWAG | 33106492 |
| TRW | DF 6198 |
| ZEKKERT | BS-5276B |
| Copyright © 2025 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 03.11~05.14 | 1400 | G4FA | SBR11 RUS | FR0211V | FP1543 | FR0212 | FP1313FT1076 | |
| 11.10~05.14 | 1600 | G4FC | SBR11 RUS | FR0211V | FP1543 | FR0212 | FP1313 |
| 05.14~12.16 | 1400 | G4FA | SBR14 RUS | FR0211V | FP1543 | FT1076 | ||
| 05.14~12.16 | 1600 | G4FC | SBR14 RUS | FR0211V | FP1543 | FR0212 | FT1076 |
| 01.14~01.19 | 1400 | G4LC | CT41 RHD | FR0211V | FP1543 | FR0212 | FP1313FT1076 | |
| 01.14~01.19 | 1400 | G4LC | CT51 | FR0211V | FP1543 | FR0212 | FP1313 | |
| 09.14~02.20 | 1600 | D4FB | PSB15 LHD | FR0211V | FP1543 | FR0212 | FP1313FT1076 | |
| 05.14~11.17 | 1600 | G4FC | PSB15 SDN | FR0211V | FP1543 | FR0212 | FP1313FT1076 | |
| 01.14~01.19 | 1400 | G4LC | CU41 SDN RHD | FR0211V | FP1543 | FR0212 | FP1313 | |
| 01.14~01.20 | 1400 | G4LC | CT41 SDN LHD | FR0211V | FP1543 | FR0212 | FT1076FP1313 |
| 09.11~05.14 | 1600 | G4FD | SB | FR0211V | FP1543 | FT1076 | ||
| 01.11~12.14 | 1600 | D4FB | SB | FR0211V | FP1543 | FR0212 | FP1313 | |
| 09.11~05.14 | 1400 | G4LC | CT41 RHD | FR0211V | FP1543 | FR0212 | FP1313 | |
| 10.10~10.14 | 1400 | G4FA | PSB11 SDN LHD | FR0211V | FP1543 | FR0212 | FP1313FT1076 | |
| 09.11~05.14 | 1600 | G4FC | PSB11 SDN | FR0211V | FP1543 | FR0212 | FT1076FP1313 | |
| 11.11~09.14 | 1400 | G4FA | SB HB | FR0211V | FP1543 | FT1076 | ||
| 09.11~05.14 | 1600 | G4FC | PSB11 HB | FR0211V | FP1543 | FR0212 | FP1313 | |
| 10.10~10.14 | 1400 | G4FA | PSB11 SDN RHD | FR0211V | FP1543 | FR0212 | FP1313 | |
| 09.11~05.14 | 1600 | G4FC | PSB11 HB LHD PR | FR0211V | FP1543 | FR0212 | FP1313FT1076 | |
| 11.10~12.14 | 1600 | D4FB | PSB11 SDN DOM | FR0211V | FP1543 | FR0212 | FP1313 | |
| 09.11~05.14 | 1400 | G4LC | CT41 LHD | FR0211V | FP1543 | FT1076 |
| 11.14~06.18 | 1400 | D4FC | PC715 RHD | FR0211V | FP1543 | FT1076 | ||
| 11.14~06.18 | 1400 | G4LC | PC715 RHD | FR0211V | FP1543 | FR0212 | FT1076FP1313 | |
| 06.18~08.20 | 1400 | G4LC | PC718 RHD | FR0211V | FP1543 | FT1076 | ||
| 06.18~08.20 | 1400 | G4LC | PC718 LHD | FR0211V | FP1543 | FR0212 | FP1313 | |
| 12.14~08.20 | 1200 | G4LA | BL51 5DR RHD | FR0211V | FP1543 | FT1076 | ||
| 11.14~09.17 | 1200 | G4LA | PC715 RHD | FR0211VFR1203V | FP1543 | FR0212 | FT1076FP1313 |
| 09.11~ | 1100 | D3FA | UB | FR0211V | FP1543 | FR0212 | FP1313 | |
| 09.11~ | 1400 | D4FC | UB | FR0211V | FP1543 | FR0212 | FP1313FT1076 | |
| 07.11~02.15 | 1600 | G4FC | DXR12 | FR0211V | FP1543 | FR0212 | FP1313 | |
| 03.11~05.15 | 1400 | G4FA | PIH12 5DR HB RHD | FR0211V | FP1543 | FR0212 | FT1076FP1313 | |
| 03.11~03.15 | 1600 | G4FD | PIH12 4DR SDN LHD | FR0211V | FP1543 | FR0212 | FP1313 | |
| 07.11~02.15 | 1400 | G4FA | DXR12 RUS | FR0211V | FP1543 | FR0212 | FP1313 | |
| 01.11~01.14 | 1400 | G4FA | PIH12 3DR HB | FR0211V | FP1543 | FR0212 | FT1076FP1313 | |
| 03.11~05.15 | 1400 | G4FA | PIH12 4DR SDN RHD | FR0211V | FP1543 | FT1076FP1313 | ||
| 03.11~05.15 | 1200 | G4LA | DN511 5DR HB RHD | FR0211V | FP1543 | FT1076 | ||
| 03.11~05.15 | 1400 | G4FA | PIH12 4DR SDN LHD | FR0211V | FP1543 | FT1076 | ||
| 03.11~05.15 | 1400 | G4FA | PIH12 5DR HB LHD | FR0211V | FP1543 | FR0212 | FT1076FP1313 | |
| 03.11~05.15 | 1200 | G4LA | PIH12 4DR SDN RHD | FR0211V | FP1543 | FT1076 |
| 01.15~06.17 | 1600 | G4FC | DXR15 SDN RU | FR0211V | FP1543 | FR0212 | FP1313 | |
| 01.15~06.17 | 1400 | G4FA | DXR15 RUS | FR0211V | FP1543 | FT1076 | ||
| 07.15~03.17 | 1200 | G4LA | PIH15 SDN LHD | FR0211V | FP1543 | FT1076 | ||
| 01.15~06.17 | 1400 | G4FA | PIH15 SDN | FR0211V | FP1543 | FT1076 | ||
| 11.14~06.17 | 1400 | G4FA | PIH15 5DR HB | FR0211V | FP1543 | FR0212 | FT1076FP1313 | |
| 01.15~06.17 | 1600 | G4FD | PIH15 SDN | FR0211V | FP1543 | FR0212 | FP1313 | |
| 01.15~04.17 | 1200 | G4LA | DN511 5DR HB RHD | FR0211V | FP1543 | FT1076 | ||
| 01.15~06.17 | 1600 | G4FC | DXR15 HB | FR0211V | FP1543 | FR0212 | FP1313 | |
| 07.15~03.17 | 1200 | G4LA | PIH15 5DR HB LHD | FR0211V | FP1543 | FT1076 | ||
| 11.14~06.17 | 1400 | G4FA | PIH15 5DR HB GCC | FR0211V | FP1543 | FT1076 |
| 01.18~ | 1400 | G4LC | PH718 RHD | FR0211V | FP1543 | FT1076 | ||
| 01.18~ | 1400 | G4LC | PH718 LHD | FR0211V | FP1543 | FR0212 | FT1076FP1313 |
