| Specification | |
|---|---|
| Type | Vented |
| Disc Thickness (Max) | 30 |
| Num. of holes | 5 |
| Height | 49.7 |
| Centering Diameter | 65 |
| Front/Rear | Front |
| Pitch Circle Ø | 112 |
| Outter Ø | 340 |
| Owner | Number |
|---|---|
| ATE | 24.0130-0225.1 |
| Blue Print | ADV184372 |
| BOSCH | 0 986 479 734 |
| BREMBO | 09.C306.11 |
| Febi | 39129 |
| FERODO | DDF2000C |
| Fri.tech. | DF1456 |
| HI-Q | SD5701 |
| LYNXauto | BN-1242 |
| Mando | MBC036129 |
| MILES | K001774 |
| MILES | K201774 |
| MINTEX | MDC2253 |
| NK | 2047141 |
| PAGID | 55298PRO |
| SASIC | 6106184 |
| SBS | 1815204714 |
| SBS | 18152047142 |
| STELLOX | 6020-1745-SX |
| SWAG | 30939129 |
| TEXTAR | 92229803 |
| TEXTAR | 92229805 |
| TRUSTING | DF1456 |
| TRW | DF6133S |
| VAG | 1K0 615 301 AD |
| VAG | 1K0615300AD |
| VAG | 3C0 615 301 C |
| VAG | 3C0 615 301 D |
| VAG | 5Q0 615 301 C |
| VAG | 5Q0 615 301 G |
| VAG | 5QN 615 301 A |
| VAG | 8S0 615 301 |
| VAG | 8S0 615 301 D |
| VAG | JZW 698 302 DG |
| ZEKKERT | BS-6469 |
| ZIMMERMANN | 600.3243.20 |
| ZIMMERMANN | 600324352 |
| Copyright © 2024 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.12~08.16 | 1800 | CJSB | 8VA | FR0659V | FP1115E | FR0731 | FP1761 | |
| 10.13~05.14 | 2000 | CJXB | 8VSS4L | FR0659V | FP1633E | FR0871V | FP1761 |
| 06.20~ | 1000 | DLAA | SDN / HB | FR0484VFR0487VFR0659V | FP1115EFP1633E | FR0731FR0871V | ||
| 11.19~ | 2000 | DSUD | SDN / HB | FR0484VFR0487VFR0659V | FP1115EFP1633E | FR0731FR0871V | ||
| 11.19~ | 2000 | DSRB | SDN / HB | FR0659VFR0484VFR0487V | FP1115EFP1633E | FR0871VFR0731 | ||
| 11.19~ | 1500 | DPCA | SDN / HB | FR0484VFR0487VFR0659V | FP1115EFP1633E | FR0731FR0871V | ||
| 11.19~ | 1400 | DGEA | SDN / HB | FR0659VFR0484VFR0487V | FP1115EFP1633E | FR0871VFR0731 |
| 08.15~08.18 | 1800 | CJSA | FV3 | FR0487VFR0659V | FP1876FP1115E | FR0731FR0867FR0871V | FP1761 | |
| 07.14~08.18 | 2000 | CUNA | FV3 | FR0487VFR0659V | FP1876FP1115E | FR0731FR0867FR0871V | FP1761 | |
| 08.18~ | 2000 | DNUF | FV | FR0659VFR0487V | FP1115EFP1876 | FR0871VFR0867FR0731 | FP1761 | |
| 09.18~ | 2000 | DHHA | FV | FR0659VFR0487V | FP1115EFP1876 | FR0871VFR0867FR0731 | FP1761 |
| 11.12~03.17 | 1400 | CXSA | 5G1_G_ | FR0796VFR0487VFR0659VFR0484V | FP1968EFP1115EFP1633E | FR0867FR0871VFR0731 | FP1761 | |
| 11.13~03.17 | 2000 | CJXB | 5G1RVR | FR0659V | FP1633E | FR0871V | FP1761 | |
| 12.16~08.20 | 2000 | DJHB | BQ1_M_ | FR0659V | FP1633E | FR0871V | FP1761 |
| 08.10~07.15 | 1800 | CDAA | 36__H_ | FR0487VFR0659V | FP1375EFP1633E | FR0339FR0871V | ||
| 08.10~12.14 | 1400 | CAXA | 36__A_ | FR0487VFR0659V | FP1375EFP1633E | FR0339FR0871V | ||
| 08.14~11.20 | 2000 | CUAA | 3G__9T | FR0659V | FP1633E | FR0871V | FP1761 | |
| 01.11~12.14 | 3600 | BWS | 36__VQ | FR0659V | FP1633E | FR0871V |
| 05.08~11.10 | 1800 | BZB | 3572J_ | FR0487VFR0930VFR0659V | FP1375EFP0915EFP1633E | FR0339FR0871V | ||
| 11.09~01.12 | 1800 | CDAA | 357_H_ | FR0930VFR0659VFR0487V | FP1375EFP0915EFP1633E | FR0871VFR0339 | ||
| 08.08~11.10 | 2000 | CBBB | 3572X_ | FR0487VFR0659V | FP1375EFP1633E | FR0339FR0871V |
| 11.16~ | 2000 | CZPA | BT1_Q0 | FR0659V | FP1633E | FR0867 | FP1761 | |
| 11.16~ | 2000 | CHHB | BT1_W0 | FR0659V | FP1633E | FR0867 | FP1761 | |
| 06.16~ | 2000 | CHHB | AD1_W_ | FR0659V | FP1633E | FR0867 | FP1761 | |
| 11.20~04.24 | 1400 | DGEA | AX1_ZY | FR0659V | FP1633EFP1115E | FR0871V | FP1761 |
| 03.17~07.20 | 2000 | CUAA | 3H749T | FR0659V | FP1633E | FR0871V | FP1761 | |
| 03.17~ | 2000 | DJHC | 3H74PT | FR0487VFR0659V | FP1115EFP1633E | FR0867FR0871V | FP1761 |
| 03.17~ | 2000 | DGVA | BW2_L_ | FR0659V | FP1633E | FR0867 | FP1761 | |
| 07.21~ | 2000 | DGVA | BJ2 | FR0659V | FP1633E | FR0867 | FP1761 | |
| 04.17~08.20 | 2000 | DGUA | BW2_V_ | FR0659V | FP1633FP1633E | FR0867 | FP1761 |
| 07.21~ | 2000 | DRNA | CD1 | FR0659V | FP1633 | FR0871V | ||
| 08.20~ | 2000 | DNPA | CD1 | FR0659V | FP1633E | FR0871V | ||
| 12.20~ | 2000 | DLBA | CD1 | FR0659V | FP1633E | FR0871V |
| 10.16~ | 2000 | CZPA | NS7_R_ | FR0659V | FP1633E | FR0867 | FP1761 | |
| 06.21~ | 2000 | DNPA | NS76UZ | FR0659V | FP1633E | FR0871V | FP1761 | |
| 10.16~06.24 | 2000 | DFHA | NS__8Z | FR0659V | FP1633E | FR0867 | FP1761 |
| 05.20~ | 1400 | DGEA | KL# | FR0484VFR0487VFR0659V | FP1115EFP1263FP1633E | FR0871V | ||
| 11.19~ | 1500 | DPBA | KL# | FR0484VFR0487VFR0659V | FP1115EFP1263FP1633E | FR0871V | ||
| 11.19~ | 1500 | DPCA | KL# | FR0484VFR0487VFR0659V | FP1115EFP1263FP1633E | FR0871V | ||
| 11.19~ | 2000 | DS# | KL# | FR0484VFR0487VFR0659V | FP1115EFP1263FP1633E | FR0871V | ||
| 03.21~ | 2000 | DN# | KL# | FR0484VFR0487VFR0659V | FP1115EFP1263FP1633E | FR0871V |
