| Specification | |
|---|---|
| Type | Vented |
| Disc Thickness (Max) | 25 |
| Num. of holes | 5 |
| Height | 52.4 |
| Centering Diameter | 68 |
| Front/Rear | Front |
| Pitch Circle Ø | 112 |
| Outter Ø | 314 |
| Disc Thickness (Min) | 23 |
| Drum Ø: | 154 |
| Structure Material | G3000 |
| Owner | Number |
|---|---|
| ATE | 24.0125-0184.1 |
| Blue Print | ADV184313 |
| BOSCH | 0 986 479 467 |
| BREMBO | 09.A820.11 |
| CAR | 142.1507 |
| CIFAM | 800-917C |
| DELPHI | BG4079 |
| FAW-VW | L8K0 615 301 |
| FAW-VW | L8KD 615 301 |
| FAW-VW | L8WD 615 301 |
| Febi | 36232 |
| FENOX | TB217962 |
| Fri.tech. | DF1334 |
| GIRLING | 6048665 |
| GRAF | DF29917C |
| INTERBRAKE | AD991V |
| LUCAS | DF4866S |
| LYNXauto | BN-1252 |
| Mando | MBC036013 |
| Metelli | 23-0917C |
| MILES | K000399 |
| MILES | K200399 |
| MINTEX | MDC2200C |
| NK | 2047132 |
| PILENGA | V981 |
| QH | BDC5709 |
| REMSA | 61292.10 |
| ROADHOUSE | 61292.10 |
| SBS | 18152047132 |
| STELLOX | 60201721SX |
| SWAG | 30936232 |
| TEXTAR | 92159903 |
| TRUSTING | DF1334 |
| VAG | 8K0 615 301 |
| VAG | 8K0 615 301 T |
| VAG | 8W0 615 301 G |
| VAG | 8W0 615 301 T |
| WOKING | D61292.10 |
| ZEKKERT | BS-5867 |
| ZIMMERMANN | 100.3330.20 |
| ZIMMERMANN | 100.3330.52 |
| Copyright © 2025 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.07~05.16 | 2000 | CSU# | SDN / EST | FR0730V | FP3276EFP1535E | FP1386 | ||
| 11.07~03.12 | 2700 | CAM# | 8K | FR0730V | FP1535E | FR0729 | FP1386 | |
| 05.07~03.12 | 1800 | CDHB | 8K____ | FR0730V | FP1535E | FR0729 | FP1386 | |
| 12.11~12.15 | 1800 | CJEB | 8K203H | FR0730V | FP1535E | FR0729 | FP1386 | |
| 05.15~06.20 | 2000 | DEUA | 8W2ABG | FR0730V | FP1953E | FR1189 | FP1898 | |
| 05.07~05.08 | 1800 | CABB | 8K____ | FR0730V | FP1535E | FR0729 | FP1386 | |
| 08.15~ | 1400 | CVNA | 8W__E_ | FR0730V | FP1953E | FR1189 | FP1898 | |
| 06.16~ | 2000 | DBPA | 8W__M_ | FR0730V | FP1953E | FR1189 | FP1898 | |
| 05.07~03.12 | 2000 | CAGA | 8K__Q_ | FR0730V | FP1535E | FR0729 | FP1386 | |
| 01.08~09.13 | 1800 | CDHA | 8K2 | FR0730V | FP1535E | FR0729 | FP1386 | |
| 10.19~ | 2000 | DEMB | 8W__9G | FR0730V | FP1953E | FR1189 | FP1898 | |
| 05.15~ | 2000 | CVKB | 8W__D_ | FR0730V | FP1953E | FR1189 | FP1898 | |
| 03.08~04.12 | 2000 | CDNC | 8K6C SDN JPN | FR0730VFR0728V | FP3276E | FR0729 | FP1386 | |
| 01.08~05.16 | 1800 | CABA | SDN / EST | FR0728VFR0730VFR0868V | FP3276EFP1535E | FR0729 | FP1386 | |
| 08.07~05.16 | 2000 | CAG# | SDN / EST | FR0730VFR0728V | FP1535EFP3276E | FR0729 | FP1386 | |
| 08.07~05.16 | 2000 | CJC# | SDN / EST | FR0728VFR0730VFR0873VFR0868V | FP3276EFP1535E | FR0729FR0866V | FP1386 | |
| 08.07~05.16 | 2000 | CMF# | SDN / EST | FR0873VFR0728VFR0730VFR0868V | FP3276EFP1535E | FR0866VFR0729 | FP1386 | |
| 06.08~05.16 | 2000 | CAE# | SDN / EST | FR0728VFR0730VFR0868V | FP3276EFP1535E | FR0729 | FP1386 | |
| 06.08~05.16 | 2000 | CPM# | SDN / EST | FR0728VFR0730VFR0868V | FP3276EFP1535E | FR0729 | FP1386 | |
| 05.15~08.18 | 3000 | CSWB | SDN / EST | FR0730VFR1345V | FP1953EFP1897 | FR1189FR0866V | FP1898 | |
| 09.13~12.15 | 2000 | CNHA | AVANT | FR0730V | FP1535E | FR0729 | FP1386 | |
| 06.08~12.15 | 2000 | CDNB | 8K__5_ | FR0730V | FP1535E | FR0729 | FP1386 | |
| 01.20~01.25 | 2000 | CVKC | 8W__9G | FR0730V | FP1953E | FR1189 | FP1898 | |
| 11.11~08.15 | 1800 | CDHA | 8K2 SDN | FR0730V | FP1535E | FR0729 | FP1386 | |
| 08.07~05.16 | 2000 | CAHA | SDN / EST | FR0730V | FP1535E | FR0729 | FP1386 |
| 05.13~05.16 | 2000 | CNCD | 8KH0A_ | FR0730VFR0728VFR0868VFR0873V | FP1535EFP3276E | FR0729FR0866V | FP1386 | |
| 11.11~05.16 | 2000 | CGLC | 8KH0_ | FR0730V | FP1535E | FR0729 | FP1386 |
