| Specification | |
|---|---|
| Type | Solid |
| Disc Thickness (Max) | 12 |
| Num. of holes | 9 |
| Height | 48.6 |
| Centering Diameter | 65 |
| Front/Rear | Rear |
| Pitch Circle Ø | 112 |
| Outter Ø | 256 |
| Drum Ø: | 140 |
| Disc Thickness (Min) | 10 |
| Structure Material | G3000 |
| Owner | Number |
|---|---|
| AP | 14852 |
| APEC | DSK2218 |
| ATE | 24.0112-0158.1 |
| ATE | 24.0312-0158.1 |
| BENDIX | 562238B |
| BOSCH | 0 986 479 155 |
| BRECO | BS 7643 |
| BREMBO | 08.9488.10 |
| BREMBO | 08.9488.11 |
| BREMBO | RD.175.000 |
| BREMBO | RS.175.000 |
| CAR | 142.1020 |
| CAR RACING | HPD 1020 |
| CIFAM | 800-725 |
| DELPHI | BG3890 |
| FERODO | DDF1276 |
| Fri.tech. | DF950 |
| GIRLING | 6042714 |
| GRAF | DF29725 |
| INTERBRAKE | VW551P |
| INTERCAR | VW551P |
| JURID | 562238J |
| JURID | 562238JC |
| KWP | 129725 |
| Lemforder | 30852 |
| Lemforder | 30852 01 |
| LPR | A1010P |
| LUCAS | DF4271 |
| LYNXauto | BN-1193 |
| MAGNETI MARELLI | 353615847540 |
| Metelli | 23-0725 |
| MINTEX | MDC1679 |
| MINTEX | MDC1679C |
| NECTO | WN1288 |
| PAGID | 54211 |
| PILENGA | 5858 |
| QH | BDC5423 |
| REMSA | 6650.00 |
| ROADHOUSE | 6650.00 |
| SBS | 1815204794 |
| TEXTAR | 92121100 |
| TEXTAR | 92121103 |
| TRUSTING | DF950 |
| TRW | DF4271 |
| VAG | 1K0 615 601 AC |
| VAG | 1K0 615 601 AJ |
| VAG | 1K0 615 601 L |
| VALEO | 186833 |
| WOKING | D6650.00 |
| ZIMMERMANN | 600.3222.00 |
| Copyright © 2024 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 10.08~12.13 | 1400 | CAV | 1K# | FR0487V | FP0768E | FR0733 | FP1108 | |
| 11.04~02.09 | 2000 | BWA | 1K13V3 | FR0292VFR0484VFR0487VFR0930V | FP0768EFP1375EFP0915E | FR0733FR0339 | FP1108 | |
| 11.05~01.09 | 1400 | BLG | 1K1 | FR0292VFR0484VFR0487VFR0930V | FP0768EFP1375EFP0915E | FR0732FR0339FR0733 | FP3260EFP1108 | |
| 08.04~09.07 | 2000 | AXX | 1K1___ | FR0292VFR0484VFR0487V | FP0768EFP1375E | FR0732FR0339FR0733 | FP1108FP3260E | |
| 01.05~07.08 | 1600 | BLF | 1K1_H3 | FR0292VFR0484VFR0487V | FP0768EFP1375E | FR0732FR0339FR0733 | FP3260EFP1108 | |
| 12.04~11.05 | 2000 | BLR | 5M1___ | FR0484V | FP1375E | FR0733 | FP1108 | |
| 07.07~08.11 | 1400 | CAXA | 1K11G5 | FR0484V | FP1375E | FR0732FR0733 | FP3260EFP1108 | |
| 06.06~01.09 | 1400 | BMY | 1K# | FR0484V | FP1375E | FR0733 | FP1108 |
| 12.03~08.10 | 2000 | BDJ | 2K__32 | FR0292V | FP0768E | FR0733 | FP1108 | |
| 06.05~08.10 | 2000 | BST | 2K__32 | FR0292VFR0484VFR0487V | FP0768EFP1375E | FR0733FR0732 | FP1108FP3260E | |
| 06.05~08.10 | 1900 | BLS | 2K__4_ | FR0292VFR0484VFR0487V | FP1375EFP0768E | FR0733FR0732 | FP3260EFP1108 | |
| 05.06~08.10 | 1400 | BUD | 2K__D2 | FR0484VFR0292VFR0487V | FP0768EFP1375E | FR0732FR0733 | FP3260EFP1108 | |
| 06.05~08.10 | 1600 | BSE | 2K__C2 | FR0484VFR0292VFR0487V | FP0768EFP1375E | FR0732FR0733 | FP3260EFP1108 | |
| 04.04~05.05 | 1600 | BGU | 2K__C2 | FR0484VFR0292VFR0487V | FP0768EFP1375E | FR0732FR0733 | FP3260EFP1108 | |
| 12.03~08.10 | 1900 | BJB | 2K__4_ | FR0484VFR0292VFR0487V | FP0768EFP1375E | FR0732FR0733 | FP3260EFP1108 | |
| 09.05~08.10 | 1900 | BSU | 2K__52 | FR0484VFR0292VFR0487V | FP0768EFP1375E | FR0732FR0733 | FP3260EFP1108 | |
| 09.07~08.10 | 2000 | BMM | 2K__64 | FR0484VFR0292VFR0487V | FP0768EFP1375E | FR0732FR0733 | FP3260EFP1108 | |
| 06.05~08.10 | 1600 | BSF | 2K__C2 | FR0484VFR0292VFR0487V | FP0768EFP1375E | FR0732FR0733 | FP3260EFP1108 |
| 11.06~05.08 | 1400 | BLG | 1T2 | FR0484VFR0487V | FP1375E | FR0733FR0339 | FP1108 | |
| 05.08~05.10 | 1400 | CAVB | 1T2 | FR0484VFR0487V | FP1375E | FR0733FR0731FR0339 | FP1108FP1456 | |
| 06.05~11.06 | 1600 | BLF | 1T1TC3 | FR0484V | FP1375E | FR0733 | FP1108 | |
| 06.05~11.05 | 2000 | BLR | 1T1TH3 | FR0484V | FP1375E | FR0733 | FP1108 | |
| 11.05~11.06 | 2000 | BVY | 1T1TH3 | FR0484V | FP1375E | FR0733 | FP1108 | |
| 06.05~05.08 | 1900 | BLS | 1T1___ | FR0484V | FP1375E | FR0733 | FP1108 | |
| 08.03~02.06 | 1900 | BKC | 1T1___ | FR0484V | FP1375E | FR0733 | FP1108 |
| 06.08~10.12 | 1400 | CAVD | 1372Q_ | FR0484VFR0930VFR0487V | FP0915EFP1375E | FR0733FR0731FR0871VFR0732 | FP1108FP1456FP3260E |
| 10.08~05.13 | 1400 | CAXA | 5K1_G_ | FR0292VFR0484VFR0487VFR0930V | FP1375EFP0768EFP0915E | FR0732FR0339FR0731FR0733FR0871V | FP3260EFP1108FP1456 | |
| 10.08~11.12 | 1400 | CAVD | 5K1_Q_ | FR0487VFR0292VFR0484VFR0930V | FP0768EFP1375EFP0915E | FR0732FR0339FR0731FR0733FR0871V | FP3260EFP1108FP1456 | |
| 02.09~11.12 | 2000 | CCZB | 5K19V3 | FR0292VFR0484VFR0487VFR0930V | FP0768EFP0915EFP1375E | FR0732FR0339FR0731FR0733FR0871V | FP1108FP3260EFP1456 |
| 11.05~10.08 | 2000 | BVZ | 1Z__N_ | FR0484V | FP1375E | FR0733 | FP1108 | |
| 05.04~10.08 | 1600 | BLF | SDN/EST | FR0292V | FP0768E | FR0733 | FP1108 | |
| 05.04~10.08 | 1600 | BGU | SDN/EST | FR0292V | FP0768E | FR0733FR0732 | FP3260EFP1108 | |
| 05.04~10.08 | 1900 | BJB | SDN/EST | FR0484VFR0292V | FP0768EFP1375E | FR0733FR0732 | FP3260EFP1108 | |
| 12.04~11.08 | 2000 | BLR | SDN/EST | FR0484V | FP1375E | FR0733 | FP1108 | |
| 05.04~10.08 | 2000 | AZV | SDN/EST | FR0484V | FP1375E | FR0733 | FP1108 | |
| 07.06~09.09 | 2000 | BMN | SDN/EST | FR0484V | FP1375E | FR0733 | FP1108 | |
| 09.05~11.08 | 2000 | BWA | SDN/EST | FR0484V | FP1375E | FR0733 | FP1108 | |
| 05.04~10.08 | 2000 | BKD | SDN/EST | FR0484V | FP1375E | FR0733 | FP1108 | |
| 12.04~11.08 | 2000 | BLX | SDN/EST | FR0484V | FP1375E | FR0733 | FP1108 | |
| 12.04~11.08 | 2000 | BLY | SDN/EST | FR0484V | FP1375E | FR0733 | FP1108 | |
| 12.04~11.08 | 2000 | BVX | SDN/EST | FR0484V | FP1375E | FR0733 | FP1108 | |
| 12.04~11.08 | 2000 | BVY | SDN/EST | FR0484V | FP1375E | FR0733 | FP1108 | |
| 06.07~10.08 | 1800 | BZB | 1Z__Q5 | FR0484V | FP1375E | FR0733 | FP1108 |
| 05.03~01.14 | 2000 | AZV | HB / SB | FR0484VFR0487V | FP1375E | FR0732FR0733FR0731 | FP3260EFP1456FP1108 | |
| 06.06~06.08 | 2000 | BUY | HB / SB | FR0484VFR0487V | FP1375E | FR0732FR0733FR0731 | FP3260EFP1456FP1108 |
