| Specification | |
|---|---|
| Type | Solid |
| Disc Thickness (Max) | 11 |
| Num. of holes | 5 |
| Height | 40.7 |
| Centering Diameter | 63.5 |
| Front/Rear | Rear |
| Pitch Circle Ø | 108 |
| Outter Ø | 271 |
| Drum Ø: | 151 |
| Disc Thickness (Min) | 9 |
| Structure Material | G3000 |
| Owner | Number |
|---|---|
| ATE | 24.0111-0171.1 |
| Blue Print | ADF124323 |
| BOSCH | 0986479763 |
| BREMBO | 08.A725.10 |
| BREMBO | 08A72511 |
| DANAHER | DR10644 |
| DELPHI | BG4386C |
| DENCKERMANN | B130719 |
| Febi | 39689 |
| FENOX | TB215289 |
| FORD | 1 704 765 |
| FORD | 1 759 531 |
| FORD | 1 845 628 |
| FORD | BV61-2A315-BA |
| FORD | BV61-2A315-FA |
| FORD | BV61-2A315-FB |
| FORD | BV612A315CB |
| FORD | BV612A315DA |
| FORD | BV612A315EA |
| FORD | BV6Z-2C026-C |
| FORD | CV6Z-2C026-A |
| FORD | G2MZ-2V026-JA |
| FORD | GU2Z-2V026-B |
| FORD | GU2Z-2V026-BB |
| HI-Q | SD5303 |
| LYNXauto | BN-1452 |
| Mando | MBC035036 |
| MILES | K211237 |
| MINTEX | MDC2358 |
| MOTORCRAFT | BRR-447 |
| MOTORCRAFT | BRRF-252 |
| MOTORCRAFT | BRRF-340 |
| MOTORCRAFT | NBRR-99 |
| SASIC | 6106297 |
| SWAG | 50 93 9689 |
| TEXTAR | 92239003 |
| TRW | DF 6139 |
| TRW | DF8028 |
| ZEKKERT | BS-5630 |
| ZIMMERMANN | 250136620 |
| Copyright © 2025 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 07.12~05.18 | 2000 | C20HDTX / ENR90 | DH | FP1668 | FR0744 | FP0973 | ||
| 01.11~05.18 | 2000 | C20HDEX / ENMG0 160PS | DH | FR0325V | FP1230 | FR0744 | FP0973 | |
| 12.14~05.18 | 1000 | C10FD0X | DH | FR0325V | FP1230 | FR0744 | FP0973 | |
| 01.11~05.18 | 2000 | C20HDEX / ENMG0 160PS | CDH | FR0325V | FP1230 | FR0744 | FP0973 |
| 10.14~06.19 | 1500 | C15HDTX | CEW | FR0743V | FP1230 | FR0744 | FP0973 | |
| 01.11~07.15 | 1600 | C16HDEZ (105PS) | CB8 | FR0325V | FP1230 | FR0744 | FP0973 | |
| 01.11~07.15 | 1600 | C16HDEZ (123PS) | CB8 | FR0325V | FP1230 | FR0744 | FP0973 | |
| 10.14~06.19 | 1600 | C16HDEZ (105/123PS) | 5DR HB RHD SG WF05 | FR0743VFR0325V | FP1230 | FR0744 | FP0973 | |
| 01.11~07.15 | 2000 | C20HDEX / ENMG0 160PS | CB8 | FR0743V | FP1230 | FR0744 | FP0973 | |
| 01.11~07.15 | 1600 | C16HDEZ (85PS) | CB8 | FR0325V | FP1230 | FR0744 | FP0973 | |
| 10.14~06.19 | 1600 | C16HDEZ (85PS) | CEW | FR0743V | FP1230 | FR0744 | FP0973 | |
| 10.14~06.19 | 1500 | C15DSOX | CEW | FR0325V | FP1230 | FR0744 | FP0973 | |
| 06.12~07.15 | 2000 | C20HD0D (240PS) | ST | FR0963V | FP1668 | FR0744 | FP0973 | |
| 10.14~06.19 | 1000 | C10FD0X | CEW | FR0325V | FP1230 | FR0744 | FP0973 | |
| 01.11~07.15 | 1600 | C16HD0Z | CB8 | FR0743V | FP1230 | FR0744 | FP0973 | |
| 02.12~11.19 | 1000 | SDN/HB/EST | FR0743VFR0325V | FP1230 | FR0744 | FP0973 | ||
| 01.10~11.19 | 1500 | EcoBoost | SDN/HB/EST | FR0743VFR0325V | FP1230 | FR0744 | FP0973 | |
| 09.14~11.19 | 1500 | TDCI | SDN/HB/EST | FR0743VFR0325V | FP1230 | FR0744 | FP0973 | |
| 01.10~11.19 | 1600 | SDN/HB/EST | FR0743VFR0325V | FP1230 | FR0744 | FP0973 | ||
| 01.10~10.14 | 1600 | EcoBoost | SDN/HB/EST | FR0743VFR0325V | FP1230 | FR0744 | FP0973 | |
| 07.10~10.14 | 2000 | Duratorq | SDN/HB/EST | FR0743VFR0325V | FP1230 | FR0744 | FP0973 | |
| 09.14~11.19 | 2000 | Duratorq | SDN/HB/EST | FR0743VFR0325V | FP1230 | FR0744 | FP0973 | |
| 12.14~11.19 | 2000 | Duratorq | ST | FR0963V | FP1230FP1668 | FR0744 | FP0973 | |
| 07.15~ | 1500 | C15HDTX | F3 (ASIA) | FR0325V | FP1230 | FR0744 | FP0973 | |
| 01.11~07.15 | 1600 | C16HDEZ (123PS) | CB8 SDN RHD | FR0325V | FP1230 | FR0744 | FP0973 | |
| 10.14~06.19 | 1600 | C16HDEZ (105/123PS) | SW EST RHD WF06 | FR0743VFR0325V | FP1230 | FR0744 | FP0973 | |
| 10.14~06.19 | 1600 | C16HDEZ (105/123PS) | SDN RHD WF04 SG | FR0743VFR0325V | FP1230 | FR0744 | FP0973 | |
| 06.14~06.19 | 1000 | C10FD0X | SDN RHD WF04 SG | FR0325V | FP1230 | FR0744 | FP0973 | |
| 03.14~11.19 | 1600 | C16HDEZ (105/123PS) | 5DR HB LHD RUS Z6F | FR0743VFR0325V | FP1230 | FR0744 | FP0973 |
