| Specification | |
|---|---|
| Type | Vented |
| Outter Ø | 330 |
| Num. of holes | 5 |
| Disc Thickness (Max) | 28 |
| Height | 73.7 |
| Centering Diameter | 85 |
| Pitch Circle Ø | 130 |
| Front/Rear | Rear |
| Drum Ø: | 210 |
| Disc Thickness (Min) | 25.8 |
| Owner | Number |
|---|---|
| APEC | DSK2284 |
| Ashika | 61-00-0918 |
| ATE | 24.0128-0149.1 |
| Blue Print | ADV184332 |
| BOSCH | 0 986 479 095 |
| BREMBO | 09.A056.11 |
| CAR | 142.1018 |
| CAR RACING | HPD 1018 |
| CIFAM | 800-883 |
| CIFAM | 800-883C |
| DELPHI | BG3775 |
| DENCKERMANN | B130624 |
| Febi | 28157 |
| FERODO | DDF1580 |
| Fri.tech. | DF561 |
| HI-Q | SD5450 |
| INTERBRAKE | PH071V |
| JURID | 562325J |
| JURID | 562393J |
| Lemforder | 30492 |
| Lemforder | 30492 01 |
| LPR | P2000V |
| LUCAS | DF4487 |
| Mando | MBC035343 |
| Metelli | 23-0883 |
| Metelli | 23-0883C |
| MILES | K210383 |
| MINTEX | MDC1612 |
| NK | 2047106 |
| PAGID | 54220 |
| PILENGA | V903 |
| PORSCHE | 955 352 401 30 |
| PORSCHE | 955 352 401 31 |
| QH | BDC5372 |
| SBS | 18152047106 |
| STELLOX | 6020-1077V-SX |
| SWAG | 30928157 |
| TEXTAR | 92122000 |
| TEXTAR | 92122005 |
| TRIALLI | DF 180117 |
| TRUSTING | DF561 |
| TRW | DF4487S |
| VAG | 7L6615601D |
| VAG | 7L6615601J |
| VAG | 7L8 615 601 C |
| VAG | 7L8 615 601 G |
| ZEKKERT | BS-5392 |
| ZIMMERMANN | 600.3229.20 |
| Copyright © 2025 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 06.06~05.10 | 4200 | BAR | 7L__B_ | FR0869V | ||||
| 05.04~11.06 | 3200 | BMV | 7LA___ | FR0427VFR0877VSET | FP3273EFP1174EFP3274EFP1263 | FR0869V | FP3275EFP3277EFP1277E | FT0096FT2070 |
| 10.05~05.10 | 3600 | BHK | 7L__E_ | FR0877VSET | FP1349FP1263 | FR0869V | FP1350FP3275EFP1277E | FT0096 |
| 04.10~03.18 | 3600 | CGRA | 7P_2__ | FP1263 | FR0869V | FP1453 | FT0987 | |
| 04.10~03.18 | 3000 | CGEA | 7P_29_ | FR0875VSET | FP1349 | FR0869V | FP1453 | FT0987 |
| 05.11~03.18 | 3000 | CRCA | 7P_2__ | FP1263 | FR0869V | FP1453 | FT0987 | |
| 11.04~05.08 | 3000 | BKS | 7L____ | FP1263 | FR0869V | FP1277E | FT0096 | |
| 11.07~05.10 | 3000 | CASA | 7L60__ | FP1263 | FR0869V | FP3275E | FT0096 | |
| 05.11~03.18 | 3000 | CJMA | 7P_2G_ | FP1263 | FR0869V | FP1453 | FT0987 | |
| 05.03~05.04 | 3200 | BKJ | 7LA_C_ | FP3273E | FR0869V | FP3275E | FT0096 | |
| 08.03~05.04 | 3200 | BAA | 7LA_C_ | FP3273E | FR0869V | FP3275E | FT0096 | |
| 05.04~11.06 | 3200 | BMX | 7LA_G_ | FP3273E | FR0869V | FP3275E | FT0096 | |
| 08.02~05.04 | 3200 | AZZ | 7LA_C_ | FP3273E | FR0869V | FP3275E | FT0096 | |
| 01.10~05.11 | 3000 | CASA | 7P52N_ | FP1263 | FR0869V | FP1453 | FT0987 | |
| 04.10~05.11 | 3000 | CASD | 7P52F_ | FP1263 | FR0869V | FP1453 | FT0987 | |
| 08.10~03.18 | 3600 | CMTA | 7P_21_ | FP1263 | FR0869V | FP1453 | FT0987 | |
| 12.02~12.06 | 4200 | AXQ | 7LA___ | FP3273E | FR0869V | FP3275E | FT0096 | |
| 01.10~03.18 | 4200 | CKDA | 7P_2T_ | FR0875VSET | FP1349 | FR0869V | FP1453 | FT0987 |
| 03.12~01.15 | 3000 | CNRB | GEP9 US | FP1263 | FR0869V | FP1453 | FT0987 | |
| 11.08~05.10 | 3000 | CATA | 7L60_3 | FP1263 | FR0869V | FP1453 |
| 05.09~05.11 | 3000 | CCMA | 4LB0U_ | FR0877VSET | FP3274E | FR0869V | FP3275E | FT0096 |
| 05.10~08.15 | 3000 | CJTC | 4LB0ZA | FR0877VSET | FP3274E | FR0869V | FP3275E | FT0096 |
| 11.05~11.07 | 3000 | BUG | 4LB0FL | FR0877VSET | FP3274E | FR0869V | FP3275E | FT0096 |
| 11.05~05.08 | 3000 | BUG | 4LB0ML | FR0877VSET | FP3274E | FR0869V | FP3275E | FT0096 |
| 08.06~06.09 | 3600 | BHK | 4LB0DL | FR0877VSET | FP3274E | FR0869V | FP3275E | FT0096 |
| 05.11~08.15 | 3000 | CLZB | 4LB0FA | FR0877VSET | FP3274E | FR0869V | FP3275E | FT0096 |
| 05.11~08.15 | 3000 | CRCA | 4LB0GA | FR0877VSET | FP3274E | FR0869V | FP3275E | FT0096 |
| 11.07~12.10 | 3000 | CASA | 4LB0PL | FR0877VSET | FP3274E | FR0869V | FP3275E | FT0096 |
| 05.09~05.12 | 3000 | CATA | 4LB5R_ | FR0877VSET | FP3274E | FR0869V | FP3275E | FT0096 |
| 08.03~12.06 | 3200 | M 02.2Y | 955 | FP3273E | FR0869V | FP3275E | FT0096 | |
| 09.07~05.10 | 3600 | M 55.01 | 957 | FP3274E | FR0869V | FP3275E | FT0096 | |
| 05.10~05.18 | 3600 | M 55.02 | 958 | FR0877VSET | FP1452 | FR0869V | FP1453 | FT0987 |
| 05.11~05.18 | 3000 | CRCA | 958 | FR0877VSET | FP1452 | FR0869V | FP1453 | FT0987 |
| 05.10~05.18 | 3000 | M 05.9E | 958 | FR0877VSET | FP1452 | FR0869V | FP1453 | FT0987 |
| 05.10~05.14 | 3000 | M 06.EC | 958 | FR0875VSET | FP1349 | FR0869V | FP1453 | FT0987 |
| 05.14~05.18 | 3000 | CVVA | 958 | FR0877VSET | FP1452 | FR0869V | FP1453 | FT0987 |
| 09.03~02.07 | 4500 | 4800 | 955 | FR0877VSET | FP3274E | FR0869V | FP3275E | FT0096 |
| 03.10~07.14 | 3600 | M 55.02 | 958 WP1AA US | FR0875VSET | FP1349 | FR0869V | FP1453 | FT0987 |
| 08.02~05.10 | 4500 | M 48.50 | 955 | FR0877VSET | FP3274E | FR0869V | FP3275E | FT0096 |
| 05.10~10.15 | 4800 | M 48.52 | 958 | FP1349 | FR0869V | FP1453 | FT0987 |
| 05.02~05.06 | 4500 | M 48.00 | 955 | FR0877VSET | FP3274E | FR0869V | FP3275E | FT0096 |
| 05.12~05.14 | 4200 | CUDB | 958 | FR0875VSET | FP1349 | FR0869V | FP1453 | FT0987 |
| 05.11~07.14 | 3000 | CGEA | 92AAM1 | FR0875VSET | FP1452FP1349 | FR0869V | FP1453 | FT0987 |
| 05.07~05.10 | 4800 | M 48.01 | 955 | FR0877VSET | FP3273E | FR0869V | FP3275E | FT0096 |
| 05.11~07.18 | 4800 | M 48.02 | 958 | FR0875VSET | FP1349 | FR0869V | FP1453 | FT0987 |
| 05.10~05.18 | 4800 | M 48.02 | 958 | FR0875VSET | FP1349 | FR0869V | FP1453 | FT0987 |
| 09.06~05.10 | 4800 | M 48.01 | 955 | FR0877VSET | FP3274E | FR0869V | FP3275E | FT0096 |
| 05.14~05.18 | 3600 | CURA | 958 | FR0875VSET | FP1349 | FR0869V | FP1453 | FT0987 |
