Image Of FR1039V
Specification
Type Vented
Disc Thickness (Max) 23
Num. of holes 5
Height 37.5
Centering Diameter 67
Front/Rear Front
Outter Ø 298
Disc Thickness (Min) 21.4
Pitch Circle Ø 112
Drum Ø: 146
Structure Material G3000
Owner Number
A.B.S. 18710
Blue Print ADG043218
BREMBO 09.D414.11
DELPHI BG4970C
MINTEX MDC3006C
NISSHINBO ND6127K
SSANGYONG 41441-35000
SSANGYONG 41441-35001
SSANGYONG 4144135002
Copyright © 2024
Years Eng Vol Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
SSANGYONG   »   Tivoli
01.15~06.19 1600 G16DF X100 RHD FR1039V FR1040 FP1313FP1848
01.15~ 1600 XDi 160 X100 FR1039V FR1040 FP1313
06.19~ 1600 D16DTF X100 RHD FR1039V FR1040 FP1313FP1848
01.15~06.19 1600 D16DTF X100 LHD FR1039V FR1040FR1084 FP1313FP1848
01.15~06.19 1600 D16DTF X100 RHD FR1039V FR1040 FP1313FP1848
01.15~06.19 1600 G16DF X100 LHD FR1039V FR1040 FP1313FP1848
06.19~ 1500 G15DTF X100 RHD FR1039V FR1040 FP1313FP1848
03.20~ 1200 G12DTF X100 RHD FR1039V FR1040 FP1313FP1848
SSANGYONG   »   XLV
01.15~06.19 1600 G16DF X100 RHD FR1039V FR1040 FP1848
