| Specification | |
|---|---|
| Type | Vented |
| Outter Ø | 294 |
| Num. of holes | 5 |
| Disc Thickness (Max) | 26 |
| Height | 46.3 |
| Centering Diameter | 69 |
| Pitch Circle Ø | 114.3 |
| Front/Rear | Front |
| Drum Ø: | 145 |
| Owner | Number |
|---|---|
| AP | 24938 |
| APEC | DSK2312 |
| ATE | 24.0126-0127.1 |
| ATE | 24.0126-0170.1 |
| Blue Print | ADA104309 |
| Blue Print | ADG04341 |
| BOSCH | 0 986 479 751 |
| BRECO | BS 8557 |
| BREMBO | 09.9598.10 |
| CAR | 142.1183 |
| CAR | 142.1476 |
| CAR RACING | HPD 1183 |
| CHRYSLER | 05105 514AA |
| CHRYSLER | 2AMV5 514AA |
| CHRYSLER | 5105514AA |
| CIFAM | 800-593 |
| DELPHI | BG3860 |
| Febi | 108436 |
| Febi | 31474 |
| FERODO | DDF1292 |
| FERODO | DDF1624 |
| Fri.tech. | DF1310 |
| Fri.tech. | DF153 |
| GIRLING | 6044431 |
| GRAF | DF29593 |
| HYUNDAI | 51712-26100 |
| INTERBRAKE | HY291V |
| INTERBRAKE | JP031V |
| KWP | 129593 |
| LPR | H2006V |
| LUCAS | DF4443 |
| LYNXauto | BN-1372 |
| LYNXauto | BN-1567 |
| Metelli | 23-0593 |
| MINTEX | MDC1654 |
| MINTEX | MDC2101 |
| MITSUBISHI | 4615A075 |
| MITSUBISHI | 4615A117 |
| MITSUBISHI | 4615A159 |
| MITSUBISHI | 4615A178 |
| MITSUBISHI | 4615A227 |
| MITSUBISHI | MN116331 |
| NECTO | WN1303 |
| NISSHINBO | ND3038K |
| NISSHINBO | ND6021K |
| PAGID | 54364 |
| Peugeot / Citroen | 16 075 005 80 |
| Peugeot / Citroen | 16 106 230 80 |
| PILENGA | V699 |
| REMSA | 61200.10 |
| REMSA | 6897.10 |
| ROADHOUSE | 6897.10 |
| SBS | 1815203415 |
| SWAG | 33102518 |
| SWAG | 90931474 |
| TEXTAR | 92136400 |
| TRUSTING | DF1310 |
| TRUSTING | DF153 |
| TRW | DF 6206 |
| TRW | DF4443 |
| TRW | DF4932 |
| TRW | DF7792 |
| VALEO | 186824 |
| Copyright © 2024 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 10.99~09.04 | 2000 | D4EA | FR0291VFR0321V | FP0864 | FR0289 | FP0813FT1066 | ||
| 10.04~09.08 | 2000 | D4EA | MH81 | FR0291VFR0321V | FP0864 | FR0289 | FP0813FT1066 | |
| 10.99~09.04 | 2700 | G6BA | FR0321V | FP0864 | FR0289 | FP0813 |
| 06.00~03.06 | 2700 | G6BA | SM | FR0321V | FP0864 | FR0289 | FP0813 | FT2100 |
| 06.00~03.06 | 2700 | G6BA | KM8S US | FR0321V | FP0864 | FR0289 | FP0813 | FT2100 |
| 06.00~03.06 | 2000 | D4EA | PA00 LHD | FR0291VFR0321V | FP0864 | FR0289 | FT1066FP0813 | FT2100 |
| 08.10~12.14 | 3600 | ERB | FR0321V | FR0477 | ||||
| 01.07~12.14 | 2400 | ED3 | JS#E41 | FR0321V | FP0866 | FR0477 | FP1037 | FT3183 |
| 01.07~12.10 | 2700 | EER | JSDP41 | FR0321V | FP0866 | FR0512 | FP0868 | FT3183 |
| 06.06~11.12 | 2000 | ECN | PM_H49 | FR0321VFR0476V | FP0866 | FR0512 | FP0868FT0919 | FT3183 |
| 05.06~06.09 | 2000 | ECD | PMBH49 | FR0321V | FP0866 | FR0512 | FP0868 | FT3183 |
| 06.09~09.12 | 2000 | 4B11 | CW4W RHD | FR0321V | FP0866 | FR0512 | FP0868 | FT3183 |
| 04.12~ | 2000 | 4B11 | GF2W | FR0321V | FP0866 | FR0671 | FP5151FP2135 | |
| 04.12~ | 2400 | 4B12 | GF3W | FR0321V | FP0866 | FR0671 | FP5151FP2135 | |
| 09.05~09.12 | 2400 | 4B12 | CW5W | FR0321V | FP0866 | FR0512 | FP0868 | FT3183 |
| 02.13~ | 3000 | 6B31 | GF4W | FR0321V | FP0866 | FR0671 | FP5151FP2135 | |
| 01.12~ | 2300 | 4N14-T | GF6W | FR0513VFR0321V | FP0530FP0866 | FR0671 | FP5151FP2135 | |
| 11.06~04.12 | 3000 | 6B31 | CW6W | FR0321VFR0513V | FP0866FP0530 | FR0514FR0512 | FP0868 | FT0086FT3183 |
| 08.12~01.21 | 2400 | 4J12 | GF8W | FR0321V | FP0866 | FR0671 | FP5151FP2135 | |
| 09.05~09.12 | 2400 | 4B12 | CW5W JPN | FR0321V | FP0866 | FR0512 | FP0868 | FT3183 |
| 05.10~ | 2000 | 4B11 | GA2W | FR0321V | FP0866 | FR0512FR0671 | FP5151FP0868 | FT3183 |
| 08.10~08.23 | 1600 | 4A92 | GA1W | FR0321V | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 |
| 05.10~11.15 | 1800 | 4B10 | GA3W | FR0321V | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 |
| 05.13~06.18 | 2200 | 4N14 | GA8W | FR0321V | FP0866 | FR0671 | FP5151 | |
| 04.10~03.15 | 1800 | 4N13 | GA6W | FR0321V | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 |
| 04.15~06.18 | 1600 | 9HD | GA7W | FR0321V | FP0866 | FR0671 | FP5151 | |
| 07.17~08.19 | 1600 | 4A92 | JMA#GA1W RHD | FR0321V | FP0866 | FR0671 | FP5151 |
| 12.06~12.19 | 2400 | 4B12 | CV5W | FR0321V | FP0866 | FR0514 | FP0868 | FT0086 |
| 12.09~11.11 | 2000 | 4B11 | CV4W | FR0321V | FP0866 | FR0514 | FP0868 | FT0086 |
| 12.12~12.18 | 2300 | 4N14-T | CV1W | FR0321V | FP0866 | FR0671 | FP5151 | |
| 12.11~12.19 | 2000 | 4J11 | CV2W | FR0321V | FP0866 | FR0671 | FP5151 | |
| 02.19~ | 2300 | 4N14-T | CV1W | FR0321V | FP2178 | FR0671 | FP2135 |
| 02.10~10.12 | 1800 | 4B10 | GA3W | FR0321V | FP0866 | FR0512 | FP0868 | FT3183 |
| 10.11~ | 1800 | 4J10 | GA4W | FR0321V | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 |
| 01.07~12.17 | 2000 | 4B11 | CY4A | FR0476VFR0321VFR0513V | FP0866FP0530 | FR0477FR0512FR0514 | FP0868FP1037 | FT3183 |
| 07.10~07.20 | 2000 | 4B11 | GA2W | FR0321V | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 |
| 01.15~ | 2400 | 4B12 | GA5W | FR0321V | FP0866 | FR0671 | FP5151 |
| 10.17~ | 1500 | 4B40 | GK1W | FR0321V | FP2178FP1258 | FR0671 | FP2135 | |
| 06.19~ | 2300 | 4N14-T | GK9W | FR0321V | FP2178 | FR0671 | FP2135 | |
| 12.17~ | 2000 | 4B11 | GK2W | FR0321V | FP2178 | FR0671 | FP2135 | |
| 03.17~11.20 | 1500 | 4B40 | GK1W JPN | FR0321V | FP2178 | FR0671 | FP2135 |
| 11.08~02.12 | 1800 | 4J10 | CY3A | FR0476VFR0321V | FP0866 | FR0512FR0477 | FP0868FT0924FP1037 | FT3183 |
| 12.08~03.15 | 2000 | 4B11-T | CX4A | FR0321V | FP0866 | FR0512 | FP0868 | FT3183 |
| 11.08~03.15 | 1800 | 4B10 | CX3A | FR0321V | FP0866 | FR0512 | FP0868 | FT3183 |
| 01.07~12.14 | 2400 | ED3 | JSZS41 | FR0321V | FP0866 | FR0512 | FP0868 | FT3183 |
| 09.06~12.10 | 2700 | EER | JS | FR0321V | FP0866 | FR0512FR0477 | FP1037FP0868 | FT3183 |
| 01.06~12.17 | 2400 | ED3 | MKUH74 | FR0321V | FP0866 | FR0477 | FP1037 | FT3183 |
| 01.07~12.17 | 2400 | ED3 | MKJL74 | FR0321V | FP0866 | FR0512FR0477 | FP0868FP1037 | FT3183 |
| 01.07~12.17 | 2000 | ECN | MKB_49 | FR0321V | FP0866 | FR0477 | FP1037 | FT3183 |
| 01.08~12.17 | 2400 | ED3 | MK__49 | FR0321V | FP0866 | FR0477 | FP1037 | FT3183 |
| 04.12~04.17 | 2000 | 4B11 | FR0321V | FP0866 | FR0671FR0512 | FP5151FP0868 | FT3183 | |
| 04.12~04.17 | 1800 | 4N13 | FR0321V | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 |
| 04.12~04.17 | 2000 | 4B11 | FR0321V | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 | |
| 04.12~04.17 | 1600 | 4A92 | FR0321V | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 | |
| 04.12~04.17 | 1600 | DV6C | FR0321V | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 | |
| 04.12~04.17 | 1800 | 4N13 | FR0321V | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 |
| 12.18~11.22 | 2000 | 4J11 | GA9W | FR0321V | FP0866 | FR0512 | FP0868 | |
| 08.12~11.22 | 1600 | 4A92 | GA1W | FR0321V | FP0866 | FR0512 | FP0868 | |
| 08.12~11.19 | 2000 | 4B11 | GA2W | FR0321V | FP0866 | FR0512 | FP0868 |
| 09.16~11.22 | 2000 | 4J11 | GF7W | FR0321V | FP0866 | FR0671 | FP5151FP2135 | |
| 09.16~11.22 | 2400 | 4J12 | GF8W | FR0321V | FP0866 | FR0671 | FP5151FP2135 |
