| Specification | |
|---|---|
| Type | solid |
| Disc Thickness (Max) | 11 |
| Num. of holes | 5 |
| Height | 40.8 |
| Centering Diameter | 72 |
| Front/Rear | Rear |
| Pitch Circle Ø | 114.3 |
| Outter Ø | 280 |
| Disc Thickness (Min) | 9 |
| Drum Ø: | 153 |
| Structure Material | G3000 |
| Owner | Number |
|---|---|
| APEC | DSK2226 |
| Ashika | 6103317C |
| ATE | 24.0111-0160.1 |
| Blue Print | ADM54384 |
| BOSCH | 0 986 479 181 |
| BREMBO | 08.9975.20 |
| BREMBO | RD.193.000 |
| BREMBO | RS.193.000 |
| CAR | 142.1209 |
| CAR RACING | HPD 1209 |
| CIFAM | 800-750 |
| DELPHI | BG3930 |
| DENCKERMANN | B130346 |
| Febi | 32775 |
| FENOX | TB218054 |
| FERODO | DDF1546 |
| Fri.tech. | DF962 |
| GIRLING | 6044204 |
| INTERBRAKE | MX031P |
| LPR | M5007P |
| LUCAS | DF4420 |
| LYNXauto | BN-1066 |
| Mando | MBC035613 |
| MAZDA | BP6Y26251B |
| MAZDA | BP6Y26251C |
| MAZDA | BP6Y26251D |
| MAZDA | BP6Y26251E |
| MAZDA | C25Y-26-251C |
| MAZDA | C25Y26251A |
| MAZDA | C25Y26251B |
| Metelli | 23-0750 |
| MILES | K010535 |
| MINTEX | MDC1717 |
| NECTO | WN1472 |
| NISSHINBO | ND5017 |
| OEM | BP6Y23251B |
| PAGID | 54306 |
| PILENGA | 5518 |
| QH | BDC5493 |
| REMSA | 6880.00 |
| ROADHOUSE | 6880.00 |
| SBS | 1815203252 |
| STELLOX | 6020-1129-SX |
| SWAG | 83932775 |
| TEXTAR | 92130600 |
| TRUSTING | DF962 |
| TRW | DF4420 |
| ZEKKERT | BS-5254 |
| ZIMMERMANN | 370.3079.00 |
| ZIMMERMANN | 370307920 |
| ZIMMERMANN | 370307952 |
| Copyright © 2025 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.03~03.09 | 2000 | LF# | BK HB | FR0306V | FP1230 | FR0483 | FP0973 | |
| 01.03~03.09 | 2000 | LF-VE | JM6BK SDN | FR0306V | FP1230 | FR0483 | FP0973 | |
| 01.03~08.11 | 2300 | L3-VE | BK | FR0306V | FR0483 | FP0973 | ||
| 03.06~03.09 | 2000 | RF-T | BK | FR0306V | FR0483 | FP0973 | ||
| 02.09~11.13 | 2500 | L5-VE | BL | FP1230 | FR0483 | |||
| 01.09~11.13 | 2300 | L3-VE | BL | FP0213 | FR0483FR0479 | FP0973 | ||
| 01.09~11.13 | 2300 | L3-VDT | BL HB | FP0213 | FR0483 | FP0973 | ||
| 01.09~11.13 | 2200 | SH-VPTS | BL | FP1230 | FR0483 | FP0973 | ||
| 07.06~03.09 | 2300 | L3-VDT | 5DR HB US | FP0213 | FR0483 | FP0973 | ||
| 06.03~07.06 | 2000 | LF# | BK HB | FR0306V | FP1230 | FR0483 | FP0973FT5253FT1278 | |
| 03.06~03.09 | 2000 | LF-VE | AEBA11 SDN RU | FR0306V | FP1230 | FR0483 | FP0973 | |
| 11.08~11.11 | 2000 | LF# | JMZBL HB | FR0306V | FP1230 | FR0483 | FP0973 | |
| 01.03~03.09 | 2300 | L3-VDT | BK | FP0213 | FR0483 | FP0973 | ||
| 03.06~03.09 | 2300 | L3-VDT | ABBA11 HB | FP0213 | FR0483 | FP0973 |
| 02.05~06.10 | 2000 | LFF7 | CR | FR0306VFR0305V | FP1230 | FR0723FR0483 | FP0973 | |
| 02.05~10.10 | 1800 | L823 | CR | FR0305VFR0306V | FP1230 | FR0483FR0723 | FP0973 | |
| 02.05~06.10 | 2000 | RF7J | CR | FR0305VFR0306V | FP1230 | FR0483FR0723 | FP0973 | |
| 09.04~03.08 | 2300 | L3-VE | CR | FR0305VFR0306V | FP1230 | FR0483FR0723 | FP0973 | |
| 06.10~08.17 | 1800 | L8 | CW | FR0306VFR0305V | FP1230 | FR0483FR0723 | FP0973 | |
| 06.10~08.17 | 2000 | LF-VE | CW | FR0306VFR0305V | FP1230 | FR0483FR0723 | FP0973 | |
| 06.10~08.17 | 2000 | LF5H | CW | FR0306VFR0305V | FP1230 | FR0483FR0723 | FP0973 | |
| 06.10~08.17 | 1600 | Y6 | CW | FR0306VFR0305V | FP1230 | FR0483FR0723 | FP0973 | |
| 10.10~08.17 | 2000 | PE-VPS | CW | FR0306VFR0305V | FP1230 | FR0723FR0483 | FP0973 | |
| 02.05~06.10 | 2000 | LFF7 | CR19 EU LHD | FR0305VFR0306V | FP1230 | FR0483FR0723 | FP0973 |
| 06.06~05.09 | 2300 | L3-VDT | BK3P | FR0306V | FP0213FP1230 | FR0483 | FP0973 | |
| 10.03~06.09 | 2300 | L3-VE | BK3P | FR0306V | FP1230 | FR0483 | FP0973 | |
| 06.09~09.11 | 2300 | L3-VDT | BL3FW | FP0213 | FR0483 | FP0973 | ||
| 09.11~11.13 | 2300 | L3-VDT | BL3FW | FP1230FP0213 | FR0483 | FP0973 |
| 02.05~09.07 | 2000 | LF-DE | CREW | FR0305V | FP1230 | FR0479FR0483 | FP0973 | |
| 08.07~07.10 | 2000 | LF-V# | CREW | FR0305V | FP1230 | FR0479FR0483 | FP0973 | |
| 05.10~02.18 | 2000 | LF-VE | CWEAW | FR0305V | FP1230 | FR0483 | FP0973 | |
| 02.05~07.10 | 2000 | LF# | CR19 | FR0305V | FP1230 | FR0479FR0483 | FP0973 |
