| Specification | |
|---|---|
| Type | Solid |
| Disc Thickness (Max) | 10 |
| Num. of holes | 5 |
| Height | 57.7 |
| Centering Diameter | 67 |
| Front/Rear | Rear |
| Pitch Circle Ø | 112 |
| Outter Ø | 300 |
| Drum Ø: | 164 |
| Disc Thickness (Min) | 8.4 |
| Structure Material | G3000 |
| Owner | Number |
|---|---|
| ATE | 24.0110-0328.1 |
| Blue Print | ADU174307 |
| BOSCH | 0 986 479 410 |
| BREMBO | 08.A612.40 |
| CAR | 142.1364 |
| CIFAM | 800-938 |
| CIFAM | 800-938C |
| Fri.tech. | DF1185 |
| ICER | 78BD6474-2 |
| INTERBRAKE | MD351P |
| Lemforder | 31910 01 |
| LPR | M2057P |
| LUCAS | DF4805 |
| MASUMA | BD-E0056 |
| MERCEDES-BENZ | A 204 423 06 12 |
| MERCEDES-BENZ | A 204 423 09 12 |
| MERCEDES-BENZ | A 204 423 15 12 |
| Metelli | 23-0938 |
| Metelli | 23-0938C |
| MINTEX | MDC2025 |
| NK | 2033101 |
| PAGID | 54633PRO |
| SBS | 18152033101 |
| TRUSTING | DF1185 |
| TRW | DF4805 |
| ZIMMERMANN | 400.3656.20 |
| Copyright © 2024 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 03.07~ | 2200 | OM 646.811 | C204 | FP1340E | FR0840 | FP1341E | ||
| 12.08~08.14 | 2200 | OM 651.911 | S204 | FR0568VFR1181DSET | FP1340E | FR0840 | FP1341E | |
| 11.08~01.14 | 2200 | OM 651.911 | W204 | FR1181DSETFR0568V | FP1340E | FR0840 | FP1341E | |
| 08.07~03.09 | 2200 | OM 646.811 | S204 | FR0568VFR1181DSET | FP1340E | FR0840 | FP1341E | |
| 03.07~02.11 | 2200 | OM 646.811 | W204 | FR0568VFR1181DSET | FP1340E | FR0840 | FP1341E |
| 01.10~12.16 | 1800 | M 271.860 | C207 | FR0568VFR0569V | FP1340EFP1342E | FR0840 | FP1341E | |
| 04.13~12.16 | 2000 | M 274.920 | C207 | FR0569VFR0568V | FP1342EFP1340E | FR0840 | FP1341E | |
| 03.13~12.16 | 2000 | M 274.920 | A207 | FR0569VFR0568V | FP1342EFP1340E | FR0840 | FP1341E | |
| 01.10~12.16 | 1800 | M 271.820 | 207.348 | FR0569VFR0568V | FP1340EFP1342E | FR0840 | FP1341E |
| 03.07~12.09 | 1800 | M 271.950 | W204 | FR0568V | FP1340E | FR0840 | FP1341E | |
| 08.07~08.14 | 1800 | M 271.950 | S204 | FR0568V | FP1340E | FR0840 | FP1341E |
| 01.09~05.16 | 1800 | M 271.860 | C207 | FR0568VFR0569V | FP1340EFP1342E | FR0840 | FP1341E | |
| 01.10~05.16 | 1800 | M 271.860 | A207 | FR0568VFR0569V | FP1340EFP1342E | FR0840 | FP1341E | |
| 04.13~02.17 | 2000 | M 274.920 | C207 | FR0569V | FP1342E | FR0840 | FP1341E | |
| 03.13~12.16 | 2000 | M 274.920 | A207 | FR0569VFR0569DSET | FP1342E | FR0840 | FP1341E | |
| 01.09~12.16 | 2200 | OM 651.911 | C207 | FR0569DSETFR0569V | FP1342E | FR0840 | FP1341E |
| 07.07~03.11 | 1800 | M 271.860 | W204 | FR0568VFR1181DSET | FP1340E | FR0840 | FP1341E | |
| 03.11~01.15 | 1800 | M 271.860 | W204 (RES) | FR1181DSETFR0568V | FP1340E | FR0840 | FP1341E | |
| 03.10~08.14 | 1800 | M 271.860 | S204 (RES) | FR0568VFR1181DSET | FP1340E | FR0840 | FP1341E | |
| 03.11~01.15 | 2200 | OM 651.913 | W204 | FR0725V | FP1340E | FR0726FR0840 | FP1341E | |
| 08.07~08.14 | 1800 | M 271.950 | S204 | FR0568VFR1181DSET | FP1340E | FR0840 | FP1341E | |
| 03.07~ | 1800 | M 271.950 | C204 | FR0568VFR1181DSET | FP1340E | FR0840 | FP1341E |
| 01.07~12.09 | 1800 | M 271.952 | W204 | FR0725VFR1181DSET | FP1340E | FR0726FR0840 | FP1341E | |
| 01.08~06.11 | 1600 | M 271.910 | W204 | FR0725VFR1181DSET | FP1340E | FR0726FR0840 | FP1341E |
| 01.07~07.09 | 3000 | M 272.947 | W204 | FR0568VFR0569DSET | FP1340EFP1342E | FR0840 | FP1341E | |
| 08.07~08.14 | 3000 | M 272.947 | S204 | FR0568VFR0569V | FP1340EFP1342E | FR0840 | FP1341E | |
| 07.07~01.14 | 3000 | M 272.948 | W204 | FR0569DSETFR0568VFR1181DSET | FP1342EFP1340E | FR0840 | FP1341E |
| 07.09~08.14 | 1800 | M 271.860 | S204 | FR0568VFR1181DSET | FP1340E | FR0840 | FP1341E | |
| 06.11~06.15 | 1800 | M 271.860 | C204 | FR0568V | FP1340E | FR0840 | FP1341E | |
| 07.09~01.14 | 1800 | M 271.860 | W204 | FR0568VFR1181DSET | FP1340E | FR0840 | FP1341E | |
| 02.08~12.12 | 2500 | M 272.921 | W204 | FR0568VFR1181DSET | FP1340E | FR0840 | FP1341E |
| 03.11~03.15 | 3500 | M 276.957 | C204 | FR0569DSET | FP1342E | FR0840 | FP1341E |
| 08.07~08.14 | 1800 | M 271.952 | S204 | FR0725VFR1181DSET | FP1340E | FR0726FR0840 | FP1341E | |
| 01.07~12.09 | 1800 | M 271.952 | W204 | FR0725VFR1181DSETFR0568V | FP1340E | FR0726FR0840 | FP1341E | |
| 04.10~01.14 | 2200 | OM 651.913 | W204 | FR0725VFR1181DSET | FP1340E | FR0726FR0840 | FP1341E | |
| 06.12~01.14 | 1600 | M 274.910 | W204 | FR0725VFR1181DSET | FP1340E | FR0726FR0840 | FP1341E |
| 08.07~12.12 | 2500 | M 272.921 | S204 | FR0568VFR1181DSET | FP1340E | FR0840 | FP1341E | |
| 08.07~10.09 | 2500 | M 272.921 | W204 | FR0568VFR1181DSET | FP1340E | FR0840 | FP1341E |
| 07.09~01.14 | 3000 | M 272.947 | W204 | FR0568VFR0569DSETFR1181DSET | FP1342EFP1340E | FR0840 | FP1341E |
