| Specification | |
|---|---|
| Type | Solid |
| Disc Thickness (Max) | 11 |
| Num. of holes | 5 |
| Height | 71.5 |
| Centering Diameter | 69 |
| Front/Rear | Rear |
| Pitch Circle Ø | 114.3 |
| Outter Ø | 302 |
| Drum Ø: | 188 |
| Owner | Number |
|---|---|
| Blue Print | ADG043159 |
| BOSCH | 0 986 479 081 |
| BREMBO | 08.B605.10 |
| DELPHI | BG4335 |
| Fri.tech. | DF1413 |
| HYUNDAI | 58411-2P000 |
| HYUNDAI | 58411-2W010 |
| KIA | 58411-2P000 |
| NIPPARTS | N3310317 |
| NISSHINBO | ND6066K |
| NK | 203534 |
| REMSA | 61373.00 |
| TRUSTING | DF1413 |
| TRW | DF 7996 |
| Copyright © 2024 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.09~09.12 | 2400 | G4KE | SH81 | FR0459V | FP1202 | FR0844 | FP1284 | |
| 08.09~08.12 | 2200 | D4HB | SH81 | FR0459V | FP1202 | FR0844 | FP1284 | |
| 08.09~09.12 | 3500 | G6DC | CMA11 US | FP1543 | FR0844 | FP1284 | ||
| 08.09~09.12 | 2400 | G4KE | CMA10 US | FP1543 | FR0844 | FP1284 | ||
| 08.09~09.12 | 3500 | G6DC | SH81 LHD | FR0459V | FP1202 | FR0844 | FP1284 | |
| 08.09~09.12 | 2400 | G4KE | PCM10 LHD | FR0459V | FP1202 | FR0844 | FP1284 |
| 05.12~07.15 | 2400 | G4KJ | PDM12 | FR0459V | FP1202 | FR0844 | FP1284 | FT1042 |
| 05.12~07.15 | 2400 | G4KE | DM LHD | FR0459VFR0787V | FP1202 | FR0844 | FP1284 | FT1042 |
| 05.12~07.15 | 2200 | D4HB | PDM12 | FR0787V | FP1202 | FR0844 | FP1284 | FT1042 |
| 05.12~07.15 | 3300 | G6DF | PDM12 | FR0787V | FP1202 | FR0844 | FP1284 | FT1042 |
| 05.12~07.15 | 2000 | G4KH | DMA US | FR0787V | FP1543 | FR0844 | FP1284 | FT1042 |
| 05.12~07.15 | 2000 | D4HA | PDM12 KDOM | FR0787V | FP1202 | FR0844 | FP1284 | FT1042 |
| 05.12~07.15 | 2400 | G4KE | DM RHD | FR0787V | FP1202 | FR0844 | FP1284 | FT1042 |
| 01.13~10.18 | 2200 | D4HB | WAGON - LONG 5DR 7P | FR0787V | FP1202 | FR0844 | FP1284 | FT1042 |
| 10.16~10.18 | 3000 | G6DG | WAGON - LONG 5DR 7P | FR0459V | FP1917 | FR0844 | FP1284 | FT1042 |
| 01.13~10.18 | 3300 | G6DF | PB813 LHD PR | FR0787V | FP1202 | FR0844 | FP1284 | FT1042 |
| 01.13~10.16 | 3300 | G6DH | WAGON - LONG 5DR 7P | FR0787V | FP1202 | FR0844 | FP1284 | FT1042 |
| 09.12~05.16 | 3300 | G6DF | PB813 LHD LONG 7P | FR0787V | FP1202 | FR0844 | FP1284 | FT1042 |
| 11.15~11.18 | 3300 | G6DH | PB816 (USA) | FR0787V | FP1917 | FR0844 | FP1284 | FT1042 |
| 08.15~01.19 | 2000 | D4HA | DM15 | FR0787V | FP1917 | FR0844 | FP1284 | FT1042 |
| 08.15~01.19 | 2200 | D4HB | PDM15 RHD | FR0787V | FP1917 | FR0844 | FP1284 | FT1042 |
| 08.15~01.19 | 2000 | G4KH | DM | FR0787V | FP1543 | FR0844 | FP1284 | FT1042 |
| 08.15~01.19 | 2400 | G4KE | PDM15 LHD | FR0459V | FP1917 | FR0844 | FP1284 | FT1042 |
| 08.15~01.19 | 2400 | G4KE | PDM15 RHD | FR0787V | FP1917 | FR0844 | FP1284 | FT1042 |
| 05.09~07.12 | 2400 | G4KE | XM09 | FR0459V | FP1202 | FR0844 | FP1284 | |
| 05.09~07.12 | 2200 | D4HB | KEURPXM09 | FR0459V | FP1202 | FR0844 | FP1284 | |
| 05.09~07.12 | 2200 | D4HB | KGENPXM09 | FR0459V | FP1202 | FR0844 | FP1284 | |
| 05.09~07.12 | 3500 | G6DC | XM09 | FR0459V | FP1202 | FR0844 | FP1284 |
| 07.12~08.14 | 2200 | D4HB | XM12 RHD | FR0459VFR0787V | FP1202 | FR0844 | FP1284 | FT1042 |
| 07.12~08.14 | 2400 | G4KJ | XM | FR0459V | FP1202 | FR0844 | FP1284 | FT1042 |
| 07.12~08.14 | 2400 | G4KE | XM12 | FR0459V | FP1202 | FR0844 | FP1284 | FT1042 |
| 07.12~08.14 | 3500 | G6DC | XM12 | FR0787V | FP1202 | FR0844 | FP1284 | FT1042 |
| 07.12~08.14 | 2000 | D4HA | XM12 | FR0787VFR0459V | FP1202 | FR0844 | FP1284 | FT1042 |
| 07.12~08.14 | 2200 | D4HB | XM12 LHD | FR0459V | FP1202 | FR0844 | FP1284 | FT1042 |
| 11.09~04.13 | 3500 | G6DC | XMA09 | FP1543FP2023 | FR0844 | FP1284 | ||
| 07.12~12.14 | 2400 | G4KJ | XM | FP2023FP1543 | FR0844 | FP1284 | FT1042 | |
| 05.09~07.12 | 2400 | G4KE | XM | FP1543 | FR0844 | FP1284 |
