| Specification | |
|---|---|
| Type | Vented |
| Disc Thickness (Max) | 26 |
| Num. of holes | 5 |
| Height | 48 |
| Centering Diameter | 71 |
| Front/Rear | Front |
| Pitch Circle Ø | 108 |
| Outter Ø | 283 |
| Disc Thickness (Min) | 24 |
| Drum Ø: | 134 |
| Structure Material | G3000 |
| Owner | Number |
|---|---|
| AC Delco | AC2570D |
| ATE | 24.0126-0121.1 |
| ATE | 24.0126-0183.1 |
| BENDIX | 562126B |
| BOSCH | 0 986 478 732 |
| BOSCH | 0 986 479 C33 |
| BREMBO | 09.8303.10 |
| BREMBO | 09.8303.75 |
| BREMBO | 09.C658.11 |
| BREMBO | 09.C825.11 |
| CAR | 142.537 |
| CIFAM | 800-794C |
| CITROEN | 16 695 773 80 |
| CITROEN | 98 059 614 80 |
| DELPHI | BG3682 |
| DELPHI | BG3835C |
| DELPHI | BG4669C |
| FERODO | DDF1132C |
| Fri.tech. | BD1457 |
| Fri.tech. | DF800 |
| GIRLING | 6041421 |
| GRAF | DF29563 |
| JURID | 562126J |
| KWP | 129563 |
| LPR | P1020V |
| LPR | P1251V |
| LUCAS | DF4142 |
| Metelli | 23-0563 |
| MINTEX | MDC2278 |
| MINTEX | MDC2600 |
| MINTEX | MDC2607 |
| NK | 203741 |
| OPEL | 3554083 |
| PAGID | 50367 |
| PAGID | 55325PRO |
| PEUGEOT | 4246.P7 |
| PEUGEOT | 4246.V4 |
| PEUGEOT | 4249.L3 |
| PEUGEOT | 98 039 181 80 |
| Peugeot / Citroen | 16 478 674 80 |
| QH | BDC5319 |
| REMSA | 61556.10 |
| REMSA | 61583.10 |
| SBS | 1815203723 |
| SBS | 1815203741 |
| TEXTAR | 92064500 |
| TEXTAR | 92111800 |
| TEXTAR | 92129400 |
| TEXTAR | 92129403 |
| TRUSTING | DF1457 |
| TRW | DF6121 |
| TRW | DF6657 |
| TRW | DF6698 |
| VALEO | 186702 |
| ZIMMERMANN | 440.3111.00 |
| ZIMMERMANN | 440.3111.52 |
| Copyright © 2024 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 05.04~12.08 | 2000 | EW10A | 4-Sedan | FR1023V | FP2335E | FP1486 | ||
| 05.04~12.08 | 2000 | EW10J4 | 4-Sedan | FR1023V | FP2335E | FP1486 | ||
| 05.04~12.08 | 1600 | DV6TED4 | 4-Sedan | FR1023V | FP2335E | FP1486 | ||
| 06.04~02.10 | 1800 | EW7A | 6D | FR1023V | FP2335E | FP1486 | ||
| 05.04~01.12 | 2000 | DW10BTED4 | FR1023V | FP2335E | FP1486 |
| 03.14~05.21 | 1200 | EB2DTS | 5-Hatchback | FR1023V | FP2310 | FR0988 | FP1890 | |
| 03.13~10.17 | 1600 | DV6FC | 5-Hatchback | FR1023V | FP2310 | FR1169 | FP2312 | |
| 10.17~04.22 | 1600 | DV6FC | 5-Hatchback | FR1023V | FP2310 | FR1169 | FP2312 | |
| 09.13~12.17 | 1600 | DV6FD | 5DR HB | FR1380VFR1023V | FP2120FP2310FP2313 | FR0988 | FP1890FP2312 |
| 04.14~05.21 | 1600 | DV6FC | T9 | FR1023V | FP2310 | FR0988 | FP1890 | |
| 03.14~05.21 | 1200 | EB2DTS | SW | FR1023V | FP2310 | FR1169 | FP2312 | |
| 03.14~01.18 | 2000 | DW10FD | WGN LHD | FR1380VFR1023V | FP2313 | FR1169 | FP2312 | |
| 01.18~09.21 | 1500 | DV5RC | EST | FR1023V | FP2310 | FR1169 | FP2312 |
| 08.14~11.18 | 1600 | DV6FC | 4-Sedan | FR1023VFR1380V | FP1966E | FR0982 | FP0973 | |
| 11.10~ | 1600 | DV6C | 4-Sedan | FR1023VFR1380V | FP1966EFP1306 | FR0982 | FP0973FP2338 | |
| 11.10~ | 2000 | DW10CTED4 | RXH | FR1023V | FP1966E | FR0982 | FP2338FP0973 | |
| 11.10~ | 2200 | DW12C | 4-Sedan | FR1023V | FP1966E | FR0982 | FP0973FP2338 | |
| 11.10~ | 1600 | EP6CDT 156PH | 4-Sedan | FR1380VFR1023V | FP1306FP1966E | FR0982 | FP0973FP2338 | |
| 11.10~08.18 | 2000 | DW10BTED4 | 508 | FR1023V | FR0982 | FP0973 |
| 11.10~ | 1600 | EP6CDT 156PH | 5-Hatchback | FR1380VFR1023V | FP1306FP1966E | FR0982 | FP0973FP2338 | |
| 11.10~11.18 | 1600 | EP6FDT | 5-Hatchback | FR1380VFR1023V | FP1306 | FR0982 | FP0973FP2338 | |
| 11.10~11.18 | 1600 | DV6C | 5-Hatchback | FR1380VFR1023V | FP1306 | FR0982 | FP0973FP2338 | |
| 03.14~01.19 | 1600 | DV6FC | WGN EU LHD | FR1023V | FR0982 | FP0973 |
| 02.13~ | 1600 | DV6C | B78 | FR1023VFR1380V | FP2313 | FR1022FR1169 | FP2311FP2312 | |
| 04.14~10.16 | 1600 | DV6FC | B78 | FR1023V | FR1022FR1169 | FP2311FP2312 | ||
| 04.14~ | 1200 | EB2DTS | B78 | FR1023V | FR1022 | FP2311 | ||
| 10.16~11.18 | 1600 | DV6FC | B78 | FR1023V | FR1022FR1169 | FP2311FP2312 |
| 06.18~ | 1200 | EB2DT | M/VAN | FR1380VFR1023V | FP2310 | FR1169 | FP2312 | |
| 06.18~ | 1600 | DV6FD | M/VAN | FR1023VFR1380V | FP2310 | FR1169 | FP2312 |
