FiT » ROTOR DISC » FR0570V Feedback Information NEW!

Image Of FR0570V
Specification
Type Vented
Outter Ø 289
Num. of holes 6
Disc Thickness (Max) 28
Height 70.5
Centering Diameter 98
Pitch Circle Ø 139.7
Drum Ø: 163.5
Front/Rear Front
Owner Number
ATE 24.0128-0226.1
Blue Print ADM54377
BOSCH 0 986 479 711
FORD 1 490 412
FORD 2M341027AA
FORD 4 429 562
FORD 6M341027AA
FORD UM5133251
FORD UR6133251
Fri.tech. DF1307
LYNXauto BN-1466
MAZDA UM51-33-251
MAZDA UR61-33-251
MINTEX MDC2217
NIPPARTS N3303091
NISSHINBO ND5052K
NK 203271
OEM UMY133251
SBS 1815203271
TRUSTING DF1307
TRW DF 6034S
TRW DF7362
Copyright © 2025
Years Eng Vol Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
MAZDA   »   BT-50
09.06~07.08 2600 G6-E ALUA07 FR0570VFR1087VFR0934V FP5158FP1574FP1374 FT5234FT5247FT5248
08.06~09.11 3000 WEAT ALUA07 FR0570VFR1087VFR0934V FP5158FP1574FP1374 FT5234FT5248FT5247
09.06~09.11 2200 F2 UN FR0570VFR1087VFR0934V FP5158FP1574FP1374 FT5234FT5248FT5247
07.08~09.12 2500 WLAA UN FR0570VFR1087VFR0934V FP5158FP1574FP1374 FT5234FT5248FT5247
03.06~03.09 2500 WLAA ALUA07 FR0570VFR1087V FP5158FP1574FP1374 FT5234FT5247FT5248
03.06~10.08 2500 WLAA AEUA06 FR0570VFR1087V FP1574 FT5248
03.06~10.08 3000 WEAT ABUA07 MM0 FR0570VFR1087V FP1574 FT5248
MAZDA   »   B2500
08.02~01.07 2500 WL AUEA05 FR0570VFR1087VFR0934V FP1574FP1374 FT5248FT5247
FORD   »   Ranger
11.08~10.12 2500 WLAA ES FR0570VFR1087V FP1574 FT2095
02.06~11.08 3000 WEAT ET FR0570VFR1087V FP1574 FT2095
05.06~12.11 2500 2.5 Diesel TI (HP) MN#40 FR0570VFR1087VFR0934V FP1574FP1374 FT2095FT5247
06.02~10.07 2500 2.5 Diesel TI (HP) EQ FR0570VFR1087VFR0934V FP1374 FT5248FT5247
02.06~09.11 2500 2.5l 16V DOHC HPCR DI TC ET FR0570VFR1087V FP1574
11.08~10.12 3000 MD30DITC MN#90 RHD TH FR0570VFR1087V FP1574 FT2095
06.02~10.07 2900 2.9L SOHC NA I4 MN#80 FR0570VFR1087VFR0934V FP1374FP1574 FT5248
02.06~12.09 2200 2.2L EFI MNCBS FR0570VFR1087VFR0934V FP1574FP1374 FT2095FT5247
11.08~10.12 2500 2.5l 16V DOHC HPCR DI TC WF#E10 LHD FR0570VFR1087V FP1574
01.09~10.12 2600 2.6L OHC EFI MNCBS FR0570VFR1087V FP1574 FT2095
FORD   »   Everest
04.03~10.07 2500 2.5 Diesel TI (HP) MNBLS FR0570VFR1087V FP1574 FT5248
03.09~ 2500 2.5 Diesel TI (HP) EP FR0570VFR1087V FP1574 FT2095
10.06~03.09 3000 3.0 Diesel HPCR DI MNCU FR0570VFR1087V FP1574 FT2095
03.09~ 3000 3.0l 16V DOHC HPCR DI TC MN#US FR0570VFR1087V FP1574 FT2095
10.06~03.09 2500 2.5 Diesel TI (HP) EU FR0570VFR1087V FP1574 FT2095
04.03~10.07 2500 2.5l 16V DOHC HPCR DI TC MNBLS FR0570VFR1087V FP1574 FT5248
03.09~01.15 2500 2.5l 16V DOHC HPCR DI TC MN#L FR0570VFR1087V FP1574 FT2095
