| Specification | |
|---|---|
| Type | Solid |
| Disc Thickness (Max) | 10 |
| Num. of holes | 5 |
| Height | 54.3 |
| Centering Diameter | 76 |
| Front/Rear | Rear |
| Pitch Circle Ø | 114.3 |
| Outter Ø | 284 |
| Drum Ø: | 168 |
| Owner | Number |
|---|---|
| Blue Print | ADG04320 |
| BREMBO | 08.A708.10 |
| CAR | 142.1384 |
| DELPHI | BG4012 |
| Fri.tech. | DF1112 |
| HYUNDAI | 58411-3K100 |
| HYUNDAI | 58411-3K110 |
| HYUNDAI | 58411-3Q000 |
| HYUNDAI | 58411-3S100 |
| HYUNDAI | 584110A100 |
| HYUNDAI | 584113K150 |
| INTERBRAKE | HY371P |
| KIA | 58411-3K150 |
| KIA | 58411-3S100 |
| LPR | H2016P |
| LYNXauto | BN-1545 |
| MINTEX | MDC2013 |
| NISSHINBO | ND6003K |
| REMSA | 6989.00 |
| ROADHOUSE | 6989.00 |
| SBS | 1815203425 |
| TEXTAR | 92166600 |
| TRUSTING | DF1112 |
| Copyright © 2024 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.06~12.07 | 2000 | D4EA | NF04 RHD | FR0458V | FP0924 | FR0581 | FP1848FP0813 | FT1106 |
| 09.04~12.07 | 2000 | G4KA | NF | FR0287VFR0458V | FP0924 | FR0496FR0581 | FP0813 | FT1106 |
| 09.04~09.06 | 2000 | D4EA | PA04 LHD | FR0458V | FP0924 | FR0581 | FP0813 | FT1106 |
| 01.11~07.14 | 3000 | G6DE | FH41 | FR0779VFR0653V | FP1543FP1444 | FR0581FR0108 | FP1848FP2044 | FT0982 |
| 09.11~06.16 | 3300 | G6DH | HG | FR0779VFR0653V | FP1412FP1444 | FR0581FR0108 | FP1848FP2044 | FT0982 |
| 09.09~03.14 | 2400 | G4KJ | YF | FR0458V | FP1444 | FR0581 | FP1848 | FT0982 |
| 07.12~04.14 | 2000 | G4NE | YF | FR0458V | FP1444 | FR0581 | FP1848 | FT0982 |
| 09.09~06.14 | 2000 | G4KH | PGFA10 US | FR0458V | FP1444 | FR0581 | FP1848 | FT0982 |
| 09.09~07.12 | 2400 | G4KJ | PGFA10 US | FR0458V | FP1444 | FR0581 | FP1848 | FT0982 |
| 11.10~07.12 | 2400 | G4KK | PGFE11 US | FR0458V | FP1444 | FR0581 | FP1848 | FT0982 |
| 12.07~01.13 | 2000 | D4EA | NF | FR0458V | FP0924 | FR0581 | FP1848 | FT1106 |
| 12.07~10.10 | 2400 | G4KE | EU41 LHD | FR0458V | FP0924 | FR0581 | FP1848 | FT1106 |
| 04.14~03.17 | 1700 | D4FD | PC114 LHD | FR0788V | FP1855 | FR0581 | FP1157 | |
| 04.14~07.17 | 2400 | G4KJ | PC215 US/CND | FR0788V | FP1855FP1295 | FR0581 | FP1157 |
| 05.14~10.16 | 2200 | D4HB | PHG15 | FR0779V | FP2023 | FR0108FR0581 | FP2044FP1848 | FT0982 |
| 11.11~06.14 | 3000 | L6DB | PHG11 | FR0653V | FP1444 | FR0581 | FP1848 | FT0982 |
| 03.12~ | 2000 | G4KD | GN | FR0779V | FP1412FP1827 | FR0581 | FP1848 | FT0982 |
| 01.10~01.13 | 2000 | G4KD | PTF11 RHD | FR0779VFR0287V | FP1412 | FR0581FR0418 | FP1848 | FT0982 |
| 04.13~03.16 | 2400 | G4KE | PTF14 RHD | FR0779V | FP1412 | FR0581 | FP1848 | FT0982 |
| 03.10~03.14 | 2000 | G4NE | PTFE11 | FR0458V | FP1444 | FR0581 | FP1848 | FT0982 |
| 10.15~04.18 | 2000 | G4ND | PD416 LHD | FR0779VFR0788V | FP1855 | FR0108FR0581 | FP1313FP1157 | |
| 02.18~01.20 | 2000 | G4ND | PD418 | FR0779VFR0788V | FP1855 | FR0108FR0581 | FP1313FP1157 | |
| 03.10~09.13 | 2400 | G4KE | PTF11 RHD | FR0779V | FP1412 | FR0581 | FP1848 | FT0982 |
| 03.10~09.13 | 2400 | G4KK | TF | FR0458V | FP1444 | FR0581 | FP1848 | FT0982 |
| 04.13~02.16 | 2400 | G4KK | PTFE14 | FR0458V | FP1444 | FR0581 | FP1848 | FT0982 |
| 12.11~09.13 | 2400 | G4KJ | TFA12 | FR0458V | FP1444 | FR0581 | FP1848 | FT0982 |
| 04.13~02.16 | 2400 | G4KJ | TFA14 | FR0458V | FP1444 | FR0581 | FP1848 | FT0982 |
| 10.15~02.18 | 2400 | G4KJ | PD516 | FR0788V | FP1855 | FR0581 | FP1157 | |
| 03.10~09.13 | 2400 | G4KJ | PTF11 | FR0458V | FP1444 | FR0581 | FP1848 | FT0982 |
| 10.15~02.18 | 2400 | G4KJ | PD416 | FR0788V | FP1855 | FR0581 | FP1157 |
| 01.09~01.16 | 3500 | G6DC | PJG08 | FR0653V | FP1295 | FR0581 | FP1157 | |
| 01.09~01.16 | 2400 | G4KJ | PJG08 | FR0653V | FP1295 | FR0581 | FP1157 | |
| 01.09~03.11 | 2700 | G6EA | PJG08 | FR0653V | FP1295 | FR0581 | FP1157 |
| 01.09~01.16 | 3500 | G6DC | PJG08 | FR0653V | FP1295 | FR0581 | FP1157 | |
| 01.09~03.11 | 2700 | G6EA | VG | FR0653V | FP1295 | FR0581 | FP1157 | |
| 01.09~01.16 | 2400 | G4KJ | VG | FR0653V | FP1295 | FR0581 | FP1157 | |
| 01.16~06.19 | 3000 | L6DB | YG | FR0653V | FR0581 |
| 02.18~01.20 | 1700 | D4FD | PD418 | FR0788V | FP1827FP1855 | FR0581 | FP1157 | |
| 05.10~06.13 | 2400 | G4KJ | PTF11 | FR0458V | FP1444 | FR0581 | FP1848 | FT0982 |
